High Speed Three/Four Axis CNC Drilling Milling Processing Center
JINAN YBKE MACHINERY CO., LTD.- After-sales Service：on-Site and Online Technical Support
- Warranty：2 Years for Main Components
- Condition：New
- Certification：ISO, CE
- Automatic Grade：Automatic
- CNC or Not：CNC
Base Info
- Model NO.：GS3Z-CNC-7000
- Voltage：380V
- X-Axis Travel：7000mm
- Y-Axis Travel：800mm
- Z-Axis Travel：320mm
- Main Axis Rev/Power：18000rpm,7.5kw
- X-Axis Speed：0-60m,Min
- Y-Axis Speed：0-24m,Min
- Z-Axis Speed：0-16m,Min
- Cutter Max. Length：135mm
- Air Pressure：0.5-0.6MPa
- Power Supply：380V 50Hz 3p
- Total Power：12kw
- Cutter Number：8
- Lubrication/Cooling：Automatic Lubrication and Spray System
- Work Area：W500*H250*L7000mm
- Overall Dimension：L11300*W2350*H2550mm
- Transport Package：Stretch Films and Into Container
- Specification：X-axis travel 7000mm
- Trademark：YBKE
- Origin：China
- Production Capacity：15 Sets,Month
Description
Overview
Detailed Photos
Product SpecificationCompany Profile
1).We have machining center, parts and components are produced by ourselves to ensure the precision.
2).Before the machine leaves our factory, we will only ship the machines after debugging and strictly test.
3).Imported electric components, extend the service life.
4).Main electric component is with 2 years warranty.
5).The after-sale service shall be lifelong responsibility system.
Product Specification
Packaging & Shipping
Wrapped in several layers of stretch films and one layer of plastic film, then put them into containers.
Exhibition
1).We have machining center, parts and components are produced by ourselves to ensure the precision.
2).Before the machine leaves our factory, we will only ship the machines after debugging and strictly test.
3).Imported electric components, extend the service life.
4).Main electric component is with 2 years warranty.
5).The after-sale service shall be lifelong responsibility system.
