Aluminum Profile Window Door Making Double Head Cutting Saw Machine

Jinan Tianchen Smart Machine Co., Ltd.
  • Condition：New
  • Certification：ISO, CE
  • CNC or Not：CNC
  • Voltage：380V
  • Application：Window Door Making Machine
  • Processing Material：Aluminium Profile

Base Info

  • Model NO.：LJZ2SA-500*5000
  • Minimum Finished Length：450mm
  • Control PLC：Schneider
  • Type：CNC Automatic
  • Cutting Angle：45 Degree and 90 Degree
  • Repeat Locating Length Tolerance：+-0.2mm
  • Cutting Angle Tolerance：+-5′
  • Product Name：Aluminium Automatic Double Head Cutting Saw
  • CNC Axis Numbers：1
  • Advantage：High Efficiency and High Accuracy
  • Production Efficiency：20 Seconds Per One Piece of Finished Profile
  • Prepayment：30%
  • Transport Package：Container
  • Specification：40GPx1
  • Trademark：TIANCHEN
  • Origin：China
  • HS Code：8461409000
  • Production Capacity：2000sets,Year

Description

Cutting Motor Power2*3.0KW  2800r/minCutting Length450~5000mmCutting Angle45°,90°Cutting Range(W*H)150*210mm in 90°; 150*150mm in 45°Cutting Speed: stepless speed regulation0~3m/minBlade Specificationφ500*φ30*4.4*3.8mmRepeat Locating Length Tolerance±0.2mmCutting Angle Tolerance±5′Contour Dimension7700*1700*1900mmWeightAbout 2500KGSAluminum Profile Window Door Making Double Head Cutting Saw MachineAluminum Profile Window Door Making Double Head Cutting Saw Machine
