Hydraulic Arch Sheet Colorful Roof Tile Crimping Panel Making Machine

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Tile Type：Colored Steel
  • Certification：CE, ISO, Ce, SGS
  • Condition：New
  • Customized：Customized
  • Usage：Roof, Wall, Floor
  • Transmission Method：Machinery

Base Info

  • Model NO.：Arch Sheet Shape Forming Machine
  • Color：Blue
  • Chain：1 Inch
  • Forming Steps：23
  • Roller：High Grade 45# Steel
  • Shaft：75mm
  • Material：Galvanized,Aluminum,Color Steel Sheet
  • Thickness：0.3-0.8mm
  • Middle Plate：14mm
  • Hydraulic System：PLC Computer
  • Electric Motor：4kw
  • Transport Package：Nude, Covered with Plastic Film
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Botou, Hebei, China
  • HS Code：845522
  • Production Capacity：30 Sets,Month

Description

Main parameter 1Suitable to processGalvanized/Aluminum/Color steel sheet2Width of plate1250mm3Thickness of plate0.3-0.8mm4RollersHigh grade 45# steel, with hard chrome plating5Forming steps166Sprocket chain1.5 inch7Pump station power4kw8Shaft75mm, high grade 45# steel, heat treatment9Hydraulic oil pumpCB-E31010WeightAbout 5.0 tons11Productivity8-12m/min12Cutting headCr12 mould steel with quenched treatment13Control systemTAIDA brand PLC control14Voltage380V 3Phase 60Hz15Motor power4kw16DimensionAbout 6.8m*1.5m*1.5m17Hydraulic pressure10-12mpa18Index error of length±1mm19The temperature range of working line-35-50°
Service
1. Free technical support and free accessories supply.
2. Engineer available to service machinery overseas.
3. One year warranty is provided.
4. Long life technical guidance for free.
5. We always offer technical support, quick response, all your inquire will be replied in 24 hours.
Terms of payment

1) Payment: 30% T/T prepaid, and pay the balance before shipping.
2) Delivery time: 30 working days.
3) Guarantee period: 12 months limited warranty starting from date of delivery. Shipping cost for parts to be replaced during warranty period have to be borne by the customer.
4) Spare parts: bearings, buttons, chains, magnetic valve, protective tube etc.
5) Installation and training:
a.If buyers visit our factory and check the machine, we will teach you how   to   install and   use   the machine, and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and CD to teach you to install and operate.
c. COST OF INSTALLATION:
The buyer should pay the installation charges (USD 80 one man one day). To the seller's appointed account by T/T before the seller's technicians go to the buyer's factory. The buyer pays the seller's technicians travel cost outside China, including round air tickets fee, accommodation and food, provide transportation from living hotel to the work place, necessary communication, and insurance, etc.
Hydraulic Arch Sheet Colorful Roof Tile Crimping Panel Making Machine
