Aluminum Window Door Machine Double Head Cutting Saw Machine

Jinan Tianchen Smart Machine Co., Ltd.
  • After-sales Service：Overseas Home Installation and Online Service
  • Warranty：12 Months
  • Condition：New
  • Certification：ISO, CE
  • Automatic Grade：Automatic
  • CNC or Not：CNC

Base Info

  • Model NO.：LJZ2SA-CNC-500X5000
  • Name：Automatic Cutting Saw
  • Function：Cutting Raw Aluminium Profile to Certain Length
  • Main Feature：Automatic
  • Average Productivity：Cutting Each Piece in 30s
  • Control System：Siemens
  • Application：Window Door Fabrication
  • Usage：Cutting Sawing Raw Profile to Length
  • Cutting Saw Blade：2 Pieces
  • Cutting Angle：45-157.5 Any Angle in The Range
  • Cutting Material：Aluminum Profile
  • Maximum Profile Height：150mm
  • Maximum Profile Width：150mm
  • Dimention：7700*1700*1900mm
  • Weight：2500kgs
  • Transport Package：Iron Pallet in Container
  • Specification：20GP
  • Trademark：Tianchen
  • Origin：Jinan, Shandong, China
  • HS Code：8461409000
  • Production Capacity：30 Sets Per Month

Description

Cutting Motor Power2*3.5KW  2800r/minCutting Length520~6000mmCutting Angle45°-157.5°Cutting LengthMax 6000mm at90°; Max 60000mm at 45°Cutter moving speed range 0~20m/minBlade Specificationφ600*φ30*4.8-Z144Repeat Locating Length Tolerance±0.2mmCutting Angle Tolerance±5′Contour Dimension9000*2000*2000mmWeightAbout 2800KGSAluminum Window Door Machine Double Head Cutting Saw MachineAluminum Window Door Machine Double Head Cutting Saw Machine
