Qt10-15 Brick Manufacturing Plant for Sale Full Automatic Zig-Zag Brick Forming Plant
Linyi Raytone Machinery Imp&Exp Co., Ltd.- After-sales Service：Provided
- Warranty：3 Years
- Certification：ISO
- Customized：Non-Customized
- Automatic Grade：Automatic
- Type：Concrete Iron Molding Machinery
Base Info
- Model NO.：QT10-15
- Dimension of Host Machine：5800*2100*3100
- Weight of Host Machine：9800kg
- Moulding Area：1196*880
- Power of Host Machine：41.6kw
- Viberating Force：100kn
- Pallet Size：960*850*30mm
- Type of All Kinds of Products：Paver, Curbstone Hollow Block, Solid, and Curbston
- Capacity：24000PCS for 400*200*200mm Hollow Block
- Method：Hydraulic Pressure
- Processing：Brick Molding Machine
- Transport Package：Suitable for Sea Transportation
- Specification：ISO CE SGS SONCAP
- Trademark：Raytone Machinery
- Origin：Linyi Shandong
- HS Code：84748090
- Production Capacity：24000 PCS of 40*20*20cm Per Day
Description
QT10-15 host brick making machine main technical parameters(1) Dimension of host machine 9400*2860*2980mm (7) water Consumption 12T/day (2) Weight of the host machine 9.8T (8) Voltage customized (3) Moulding period 12-20S (9) Total required machine power 103.3 (4) pallet size 1100*900*30mm (10) Diesel Generator capacity 120KVA (5) Vibration force 120KN (11) workshop area 250-300 m2 (6) labour 5 to 7 (12) Land Area 2500-6500 m2
make the weight error less than ±5%,the intensity error less than≤±15%.
4.. Capacity of different blocks models under QT10-15 Brick Making Machine
5. Why choose RAYTONE QT10-15 Brick making machine?
The QT10-15 automatic brick machine is with high vibration and 120KN pressure, which can guarantee the produced blocks has high density and high strength.
QT10-15 automatic brick making machine is with advanced technology on mechanical engineering and hydraulic systems. RAYTONE brick making machine mechanical design is improving at any time as per trouble shooting feedback from the users. RAYTONE hydraulic system is using CYLYCA brand electromagnetic valves, can give the brick machine a fast response for every movements.
Electric control system consists of imported color touch screen and programmed PLC with data input and output device, including safety logical control and trouble shooting system.
The PLC control panel is equipped with the frequency converter, this guarantee the automatic brick machine work smooth, because the vibration motors are vibrating in different frequency, the frequency changes very often, during the raw materials are being feeding into the bottom mould, the vibration motors are vibration slowly, once the raw materials feeding procedure is finished, the vibration becomes fast and fiercely. So the frequency converter is used to guarantee the vibration works smooth and fast.
PLC intelligent control system which equipped with data input and output device,advanced safety logic and fault self-diagnosis system is adopted in full of the production procedure.
Vibration analyzing system:
detecting the vibration frequency, vibration amplitude,vibration acceleration and noise of the whole machine,so as to adjust the vibration to optimum efficiency
6. FAQ
(1) What is the raw materials formula for concrete blocks
There are several formula for different raw materials, the formula can be adjusted as per the client raw materials and their ratios;
The normal formula is as below:
Standard concrete block: Cement 9-12%, sand 40%, stone 45%, water 3%
Light concrete block: Cement 9-12%, slag 80-90%, water 3%
Cement 9-12%, sand 10-20%, stone 30-40%, slag 25-50%, water 3%
Cement 8%-10%, sand 30%-40%, stone 50%-60%
Cement 8%, sand 60%, Fly ash 30%, gypsum 2%.
(2) how to confirm which model block making machine is suitable for the client?
There are two ways to confirm, firstly if the client have a budget, can recommend the block machine model as per the budget;
Secondly is by the block making machine daily capacity:
The client need to confirm what size brick or block to produce, and how many per day
What is the local voltage and frequency.
What is the receiving port to quote the shipping cost.
Then we can provide an official quotation the the client.
Welcome contact us if you are interested in block making machine.
make the weight error less than ±5%,the intensity error less than≤±15%.
4.. Capacity of different blocks models under QT10-15 Brick Making Machine
| Size(LxWxH) (mm) | Forming Period (S) | Pcs/ Mould | Pcs/Hour | Pcs/ 8 hours | |
| (1) | hollow block 400*250*200 | 15 | 8 | 1920 | 15360 |
| (2) | hollow block 400*200*200 | 15 | 10 | 2400 | 19200 |
| (3) | hollow block 400*150*200 | 15 | 12 | 2880 | 23040 |
| (4) | hollow block 400*100*200 | 15 | 18 | 4320 | 34560 |
| (5) | Solid Brick 240*50*115 | 15 | 52 | 12480 | 99840 |
| (6) | Porous Brick 240*115*90 | 15 | 24 | 5760 | 46080 |
| (7) | Curbstone 500*200*300 | 15 | 4 | 960 | 7680 |
| (8) | "I" shape paver brick 200*163*60 | 20 | 18 | 3240 | 25920 |
| (9) | "S" Shape Paver Brick 225*112.5*60 | 20 | 24 | 4320 | 34560 |
| (10) | Holland Brick 200*100*60 | 20 | 28 | 5040 | 40320 |
| (11) | Square Paver 250*250*60 | 20 | 12 | 2160 | 17280 |
5. Why choose RAYTONE QT10-15 Brick making machine?
The QT10-15 automatic brick machine is with high vibration and 120KN pressure, which can guarantee the produced blocks has high density and high strength.
QT10-15 automatic brick making machine is with advanced technology on mechanical engineering and hydraulic systems. RAYTONE brick making machine mechanical design is improving at any time as per trouble shooting feedback from the users. RAYTONE hydraulic system is using CYLYCA brand electromagnetic valves, can give the brick machine a fast response for every movements.
Electric control system consists of imported color touch screen and programmed PLC with data input and output device, including safety logical control and trouble shooting system.
The PLC control panel is equipped with the frequency converter, this guarantee the automatic brick machine work smooth, because the vibration motors are vibrating in different frequency, the frequency changes very often, during the raw materials are being feeding into the bottom mould, the vibration motors are vibration slowly, once the raw materials feeding procedure is finished, the vibration becomes fast and fiercely. So the frequency converter is used to guarantee the vibration works smooth and fast.
PLC intelligent control system which equipped with data input and output device,advanced safety logic and fault self-diagnosis system is adopted in full of the production procedure.
Vibration analyzing system:
detecting the vibration frequency, vibration amplitude,vibration acceleration and noise of the whole machine,so as to adjust the vibration to optimum efficiency
6. FAQ
(1) What is the raw materials formula for concrete blocks
There are several formula for different raw materials, the formula can be adjusted as per the client raw materials and their ratios;
The normal formula is as below:
Standard concrete block: Cement 9-12%, sand 40%, stone 45%, water 3%
Light concrete block: Cement 9-12%, slag 80-90%, water 3%
Cement 9-12%, sand 10-20%, stone 30-40%, slag 25-50%, water 3%
Cement 8%-10%, sand 30%-40%, stone 50%-60%
Cement 8%, sand 60%, Fly ash 30%, gypsum 2%.
(2) how to confirm which model block making machine is suitable for the client?
There are two ways to confirm, firstly if the client have a budget, can recommend the block machine model as per the budget;
Secondly is by the block making machine daily capacity:
The client need to confirm what size brick or block to produce, and how many per day
What is the local voltage and frequency.
What is the receiving port to quote the shipping cost.
Then we can provide an official quotation the the client.
Welcome contact us if you are interested in block making machine.
