H Type Seamless Welding Machine Door and Window Making Machine

JINAN YUEFENG MACHINERY CO., LTD.
  • Condition：New
  • Certification：ISO, CE
  • Automatic Grade：Semi-Automatic
  • CNC or Not：not CNC
  • Voltage：220V
  • Model：Shv2-100

Base Info

  • Model NO.：SHV2-100
  • Input Voltage：220V 50Hz
  • Input Power：2.2kw
  • Air Pressure：0.4~0.6MPa
  • Air Consumption：120L,Min
  • Welding Length：100mm
  • Welding Height：110mm
  • Overall Dimension：3800*800*1400mm
  • Transport Package：Wooden Box
  • Specification：3800*800*1400mm
  • Trademark：YueFeng
  • Origin：China
  • HS Code：8477800000
  • Production Capacity：30 Window Per Day

Description

Basic Info.

Model NO. SHV2-100 Input Voltage 220V 50Hz Input Power 2.2kw Air Pressure 0.4~0.6MPa Air Consumption 120L/Min Welding Length 100mm Welding Height 110mm Overall Dimension 3800*800*1400mm Transport Package Wooden Box Specification 3800*800*1400mm Trademark YueFeng Origin China HS Code 8477800000 Production Capacity 30 Window Per Day

Product Description

H Type Seamless Welding Machine Door and Window Making MachineSHV2-100
  H Type Seamless Welding Machine (single side)

H Type Seamless Welding Machine Door and Window Making Machine

1.SHV2 is especially designed for making PVC door and windows,
2.It can process "H" shape at one time;
3.All transmissions adopt air pressure, the motion pair adopts linear guide unit with high accuracy, easy to maintenance;
4.It adopts Omron PLC (programmable control) to control whole machine program.
5.The whole machine is made of high quality, high intensity steel to satisfy heavy working.

Technical Parameter:
Model  SHV2-100
Input voltage220V 50Hz
Input power   2.2Kw
Air pressure   0.4~0.6MPa
Air consumption120L/min
Max. Welding height100mm
Max. Welding width 110mm
Overall dimension3800×800×1400mm




H Type Seamless Welding Machine Door and Window Making Machine
H Type Seamless Welding Machine Door and Window Making Machine
H Type Seamless Welding Machine Door and Window Making Machine
H Type Seamless Welding Machine Door and Window Making MachineH Type Seamless Welding Machine Door and Window Making MachineFAQ

1.Are your company a trading one or a factory?
Factory + trade (integration), 36 years' focusing on Upvc,Aluminum Window and Doors Equipment ,insulating glass equipment and curtain wall equipment.

2.After an order is placed, when to deliver?

♦ Generally about 15 days,  If  we have inventory, we can arrange shipment within 5 days.
♦ Please be aware that our production lead times depend on specific items and item quantities.
3.What about the warranty with after - sales services?
♦ 24 months warranty. Besides,we can help you to solve your problem freely;

♦ After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problem encountered while using our product, handles guest problems and complaints in a professional and timely.
4.What about the services and product' quality?
♦ Each machine must be carried out 100% quality examination and test before shipment.

♦ And all machines meet ISO and CE certification.
5. We don't know the machine operation, what should we do?

♦ We can send engineer to your place, or we provide video training to show you how to install & operate, let engineer help you online.
