High Quality CNC Double Head Cutting Machine CNC Cutting Saw for Industrial Aluminum/Aluminum /UPVC Window Door /Curtain Wall with Good Service
Jinan Seth Intelligent Equipment Co., Ltd.- Warranty：24months
- Condition：New
Base Info
- Model NO.：SETH-CNC-500*5000fom
- Certification：ISO, CE, SGS
- Automatic Grade：Automatic
- CNC or Not：CNC
- Voltage：380V
- Powr：380V,50Hz
- Saw Head Motor：2X3.0kw 3000r,Min
- Working Pressure：0.6-0.8MPa
- Air Supply：60L,Min
- Cutting Length：280-5000mm(Min 200mm)
- Cutting Width：Max.150mm
- Max.Cutting Slope：45° (150X170mm)T90° (135X345mm)
- Max.Square Pipe Cutting：150X200mm
- Cutting Angle：90°, 45°
- Feeding Speed：0-4m,Min
- Saw Blade Specification：ø500 × ø30 × 4.4 Z120
- Weight：2000kg
- Repetitive Fixed-Length Accuracy：≤ 0.1mm
- Cutting Angle Tolerance：±3 ′
- Flatness of Cutting Profile：≤ 0.2mm
- Transport Package：Wooden Box
- Specification：6550X1300X1800mm
- Trademark：SETH
- Origin：Jinan
- HS Code：846150009
- Production Capacity：60000 Square Meters,Years
- Package size per unit product：655.00cm * 130.00cm * 180.00cm
- Gross weight per unit product：2200.000kg
