5 Axis CNC Double Head Saw for Aluminum Profile
Jinan Tianchen Smart Machine Co., Ltd.- Condition：New
- Certification：ISO, CE
- Automatic Grade：Semi-Automatic
- CNC or Not：CNC
- Voltage：Customized
- Power Supply Voltage：380V
Base Info
- Model NO.：LJB2H-5CNC-600X6000
- Sawing Motor Power：2X3kw
- Working Pressure：0.6~0.8MPa
- Saw Blade Specifications：Dia600xdia38X4.8X 4.2X144p
- Saw Blade Angle：45 - 90 Degree Arbitrary Angle
- Table Rotation Angle：45 - 135 Degree Arbitrary Angle
- Cutting Length：700mm -- 5000mm (90 Degree)
- Shipping：by Sea
- Prepayment：30%
- Weight：3500kg
- Coutour Dimension：9200*1800*2000mm
- Cutting Angle Tolerance：±5′
- Repeat Locating Length Tolerance：±0.2mm
- Blade Specification：Dia: 600*30*4.8 Z=144
- Cutting Feeding Speed：0~3m,Min
- Transport Package：Fixed on Pallet
- Specification：9200x1800x2000mm
- Trademark：TIANCHEN
- Origin：Jinan, Shandong, China
- HS Code：8461419000
- Production Capacity：2000 Units Per Year
Description
About 3500kgs
