High Precesion Arbitray Angle CNC Double Head Aluminum Door Frame V-Cut Cuting Machine
Jinan Tianchen Smart Machine Co., Ltd.- Condition：New
- Certification：ISO, CE
- Automatic Grade：Semi-Automatic
- CNC or Not：CNC
- Voltage：Customized
- Cutting Motor Power：2*3.5kw
Base Info
- Model NO.：LJB2EA-CNC-600*6000
- Cutting Motor Rotary Speed：2800r,Min
- Blade Specification：Dia 600*30*4.8mm
- Cutter Feeding Speed：Stepless Speed Regulation 0~3m,Min
- Cutter Moving Speed Range：0~20m,Min
- Cutting Length：520~6000mm at 90°820~6000mm at 45°
- Cutting Width：180mm
- Cutting Height：240mm
- Cutting Angle：45°~157.5°
- Repeat Locating Length Tolerance：±0.2mm
- Cutting Angle Tolerance：±5′
- Contour Dimension：9000*2000*2000mm
- Weight：2800kg
- Transport Package：40gp
- Specification：9000*2000*2000mm
- Trademark：Tianchen
- Origin：Jinan. Shandong, China
- HS Code：8461409000
- Production Capacity：100 Sets Per Month
Description
About 2800kgs
