Lime Kiln for Limestone Manufacturers Lime Making Process
Shandong Tianhang Machinery Equipment Co., Ltd.- After-sales Service：Engineers Available to Service Machinery Overseas
- Warranty：3-5 Years
- Certification：CE, ISO
- Condition：New
- Customized：Customized
- Automatic Grade：Automatic
Base Info
- Structure：Vertical
- Transmission Method：Machinery
- Voltage：380V,50Hz or 60Hz
- Worker Training：Offer
- Plant Installation：Engineer Guidance
- Experience：More Than 15 Years
- HS：8417804000
- Spare Parts：Free Offer
- Application：Lime,Cement Making, Mineral Operation
- Transport Package：Sea Worthy Packing or as Required
- Specification：3.0m dia*18.5m-5.8m dia*31.5m
- Trademark：Tianniu
- Origin：Shandong, China
- HS Code：8417804000
- Production Capacity：60 Sets,Year
Description
Capacity(t/d)
Effective Volume
Effective Height
Effective Section
Limestone Size
Heat Consumption
CaO
Activity
(m3)
(m)
Dia.(m)
(mm)
(kJ/kg)
(%)
(mL)
100
98
20
Ø2.5
30~60/40~80
<4600
>90
>300
120
141
20
Ø3.0
30~60/40~80
<4600
>90
>300
150
202
21
Ø3.5
30~60/40~80
<4500
>90
>300
200
301
24
Ø4.0
30~60/40~80
<4500
>90
>300
300
397
25
Ø4.5
30~60/40~80
<4400
>90
>300
400
491
25
Ø5.0
30~60/40~80
<4200
>90
>300
500
735
26
Ø6.0
30~60/40~80
<4200
>90
>300
Remarks: All above data are for reference only.
Capacity(t/d)
Effective Volume
Effective Height
Effective Section
Limestone Size
Heat Consumption
CaO
Activity
(m3)
(m)
Dia. or L×W(m)
(mm)
(kJ/kg)
(%)
(mL)
50
70
20
Ø2.0
30~60/40~80
<4600
>90
>300
70
80
20
Ø2.5
30~60/40~80
<4600
>90
>300
80
100
20
Ø2.5
30~60/40~80
<4500
>90
>300
100
120
20
Ø2.7
30~60/40~80
<4500
>90
>300
120
140
20
Ø3.0
30~60/40~80
<4400
>90
>300
130
150
21
Ø3.0
30~60/40~80
<4200
>90
>300
150
200
20
2.5×4.5
30~60/40~80
<4200
>90
>300
Remarks: Above data are for reference only, and suitable for Vertical Kiln which use low heat fuel. Utilization coefficient of Vertical Kiln which use high heat fuel is higher.
Packaging & Shipping
Company Profile
Our Product
Our Advantages
FAQ
1.Why us?
We provide professional industrial furnace and industrial design as customer order.
2.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every product before delivery.
3.Guaranteed?
If products' quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
4.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that " for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity".
