CNC Drilling and Milling Machine for Making Aluminum Windows
JINAN YBKE MACHINERY CO., LTD.- After-sales Service:on-Site and Online Technical Support
- Warranty:2 Years for Main Components
- Condition:New
- Certification:ISO, CE
- Automatic Grade:Automatic
- CNC or Not:CNC
Base Info
- Model NO.:ZX3Z-CNC-800
- Voltage:380V
- X-Axis Travel:800mm
- Y-Axis Travel:300mm
- Z-Axis Travel:200mm
- Main Axis Rev:18000r,Min
- Main Axis Power:3kw
- X-Axis Speed:0-60m,Min
- Y-Axis Speed:0-48m,Min
- Z-Axis Speed:0-20m,Min
- X-Axis Locating Accuracy:+-0.05mm
- Y-Axis Locating Accuracy:+-0.05mm
- Z-Axis Locating Accuracy:+-0.02mm
- Repeat Locating Accuracy:+-0.02mm
- Roughness:Ra 6.3um
- Total Power:4kw
- Dimension:1500*1420*1750mm
- Transport Package:Stretch Films and Plywood Case
- Specification:X-axis travel 800mm
- Trademark:YBKE
- Origin:China
- Production Capacity:20sets,Month
Description
Overview
Detailed Photos



Company Profile




Product Description
Packaging & Shipping
If you buy a few machines that need to be loaded in one or two containers, we pack this machine with several layers of stretch films and one layer of plastic film. If the order is not enough to be loaded in a container, we packed it in plywood case and send it to QINGDAO port to ship.
About the delivery time, it usually can be delivered in 10 working days.
Exhibition
