• Model NO.：Lxd-200
• Input Voltage：380V 50Hz
• Input Power：1.5kw
• Air Pressure：0.4~0.6MPa
• Air Consumption：100L,Min
• Motor Rotation Speed：2800r,Min
• Milling Angle：-65°~ +65°
• Max Milling Range：200×42.5×75mm
• 200×42.5×75mm：φ115~200mm
• Overall Dimension：880*830*1390mm
• Transport Package：Wooden Box
• Specification：880*830*1390mm
• Trademark：YueFeng
• Origin：China
• HS Code：8477800000
• Production Capacity：40 Window Per Day

Basic Info.

Model NO. Lxd-200 Input Voltage 380V 50Hz Input Power 1.5kw Air Pressure 0.4~0.6MPa Air Consumption 100L/Min Motor Rotation Speed 2800r/Min Milling Angle -65°~ +65° Max Milling Range 200×42.5×75mm 200×42.5×75mm φ115~200mm Overall Dimension 880*830*1390mm Transport Package Wooden Box Specification 880*830*1390mm Trademark YueFeng Origin China HS Code 8477800000 Production Capacity 40 Window Per Day

Product Description

                              PVC Profile End Milling Machine



1.Used for processing various profiles' end.
2.Worktable can adjust vertically to make it suitable for different profiles.
For end milling of transom and door frames in UPVC and aluminum profile.
Automatic feeding.
Various angle mullion milling for arch window or other special shape window.
Hand wheel for different height adjustment.


Technical Parameter:

Model	LXD-200
Input voltage	380V 50Hz
Input power	1.5kw
Air pressure	0.4~0.6MPa
Air consumption	100L/min
Motor rotation speed	2800r/min
Milling angle	-65°~ +65°
Max milling range	200×42.5×75mm
Milling cutter diameter	φ115~200mm
Overall dimension	880×830×1390mm

FAQ

1.Are your company a trading one or a factory?
Factory + trade (integration), 36 years' focusing on Upvc,Aluminum Window and Doors Equipment ,insulating glass equipment and curtain wall equipment.

2.After an order is placed, when to deliver?

♦ Generally about 15 days,  If  we have inventory, we can arrange shipment within 5 days.
♦ Please be aware that our production lead times depend on specific items and item quantities.
3.What about the warranty with after - sales services?
♦ 24 months warranty. Besides,we can help you to solve your problem freely;

♦ After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problem encountered while using our product, handles guest problems and complaints in a professional and timely.
4.What about the services and product' quality?
♦ Each machine must be carried out 100% quality examination and test before shipment.

♦ And all machines meet ISO and CE certification.
5. We don't know the machine operation, what should we do?

♦ We can send engineer to your place, or we provide video training to show you how to install & operate, let engineer help you online.
