• Model NO.：VP60
• Condition：New
• Processing：Brick Molding Machine
• Method：Vacuum Extruder
• Exported：25 Countries
• Agent：Nepal, India, Bangladesh, Egypt, Venezuela
• Function：Energy Saving
• Raw Material：Clay. Mud Soil
• Material：All Steel
• Transport Package：Container
• Trademark：BRICTEC
• Origin：China
• HS Code：8474
• Production Capacity：15000~21000PCS,H

SpecificationVP45AVP45BVP50AVP50BOutput (standard PCS/h)10000-1400010000-1400012000-1600012000-16000Diameter of Extrusion Reamer(mm)450450500500Rotary Speed of Extrusion Reamer(r/min)24(Customizable)24(Customizable)28(Customizable)28(Customizable)Distribution Power (kW)110+55+7.5X2110+55+7.5X2132+55+7.5X2132+55+7.5X2Allowable Extrusion Pressure
(MPa)4343Vacuum(MPa)-0.096-0.096-0.096-0.096Model of Upper ReducerZ335ZQ65Z335ZQ65Model of Lower ReducerN560ZQ100N560ZQ100Model of Vacuum PumpSK-6SK-6SK-6SK-6

Advantage:
1. High quality, orginal price,
2. Energy saving, produce hollow or solid bricks
Best soil clay brick extruder making machine
Best soil extruder (jkb), bricks making machineis suitable to produce all kinds of hollow or solid brick & block, all kind of clay, shale, coal slack, fly ash etc, many types of machine can be choosed depend on the raw material.
Wear resistant metal spraying technology was applied to the screw, pug mill, axis of screw and the body of extruder are treat with seasoning, conditioning, quenching treatment.

The harden surface gear was adopted in reducer, clutch are a component with own patent, all the treatments make the machine life-saving
Meanwhile the reasonable design, compact structure reduce the energy consumption, without any shaking during working, even the extruder can working normal without holding down bolt.

Best soil clay brick extruder making machine
Model: Jkb
Production capacity (pieces/h): 7 000~14, 000 pieces (standard brick)
Extrusion pressure (mpa): ≥ 2.5
Required power (kw): Upper stage: Y280m-6-55
Lower stage: Y315m-6-132
Vacuum pressure: ≥ -0.092
Main shaft speed (rpm): Upper stage: 38rpm
Lower stage: 25rpm
Shaping moisture content (wet basis %): 12 ~ 20
Required vacuum pump (water circulation type): 2sk ~ 6 ~ 2sk-12
Required electric motor: Y15 ~ 22kw
Overall dimension mm length × Width × Height: 5 700× 1, 850× 2, 510
