• Model NO.：836+836
• Color：as You Like
• Trade or Factory：Factory
• Guarantee：1 Year
• Life Time：10 Years
• Service：Provide Engineer to Install The Machines
• Brand Name of PLC：as Customer Request
• Drawing：Designed as Customer Request
• Power：38V, 50Hz, 3 Phrase or as Your Like
• Decoiler Type：Manul, Electric, Hydraulic
• Control System：PLC
• Transport Package：Main Machine Nude Packing with Plastic Film
• Specification：8800*1500*1500
• Trademark：xinnuo
• Origin：China
• HS Code：8455221000
• Production Capacity：30 Sets Per Month

Main parameter of  Double Layer Rolling Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1000mm/1200mm/1250mm

3

Thickness of the plate

0.3-0.8mm

4

De-coiler

Manual one, can load 5 tons raw material

5

Rollers for forming

12+12 rows (As customer request)

6

Diameter of the roller

80mm

7

Rolling material

Carbon Steel 45#

8

Main motor power

4kw

9

Productivity

8-12m/min

10

Cutting method

Hydraulic mould cutting

11

Material of the cutting blade

Cr12

12

Hydraulic cutting power

3kw

13

Processing precision

Within 2.00mm

14

Control system

Delta PLC control

15

Side panel of machine

14mm

16

Main structure of the machine

300 H steel

17

Weight

About 6.2 T

18

Dimensions

8.5*1.45*1.1m

19

Voltage

380V 50Hz 3phases
