Lgs 89 Vertex Bd Small Prefabricated Steel Channel Villa House Frame Machine

HEBEI XINNUO ROLL FORMING MACHINE CO., LTD.
  • Warranty：1 Year
  • Certification：CE, ISO9001
  • Customized：Customized
  • Condition：New
  • Automatic Grade：Automatic
  • Capicity of Decoiler：5000kgs

Base Info

  • Model NO.：89
  • Main Motor Type：Three-Phase Asynchronous
  • Motor Power：11kw
  • Thickness of Raw Material：0.8-1.2mm
  • Processing Precision ：Withint1.0mm
  • Diameter of Main Shaft：50mm
  • Roller Stations：12
  • Name：Stud Track Profile Roll Forming Machine for Gypsum
  • Weight of Machine：About 4.5 Tons
  • Processing Speed：15-35m,Min
  • Transport Package：Main Machine with Film by Container Shipping.
  • Specification：size: about 4.8*1.0*1.3m
  • Trademark：KXD
  • Origin：China
  • HS Code：8455221000
  • Production Capacity：3000 Sets,Year

Description

Main parameters of LGS 89 vertex BD Small Prefabricated Steel Channel Villa House Frame Machine 1Suitable to processsteel2Width of the feeding materialMax. 500mm3Roller station12 rows4Thickness of feeding material0.8-1.2mm5Productivity15-35m/min6Rollers' material45# steel7Diameter of shaft50mm8WeightAbout 3.5T9Size4800*1000*1300mm10Voltage380V  50HZ  3phases11Main motor power11 kw12Hydraulic cutting power5.5 kw

Lgs 89 Vertex Bd Small Prefabricated Steel Channel Villa House Frame Machine
Lgs 89 Vertex Bd Small Prefabricated Steel Channel Villa House Frame Machine
Lgs 89 Vertex Bd Small Prefabricated Steel Channel Villa House Frame Machine

If you need any type of roll forming machine, please contact me at any time:
