Building Material Making Machinery

Drywall Metal Track & Stud Making Machines

Cangzhou Nexus Machinery Co., Ltd.
  • Warranty:1 Year
  • Certification:CE, ISO9001
  • Customized:Customized
  • Condition:New
  • Control Type:Electric
  • Automatic Grade:Automatic

Base Info

  • Model NO.:NX80-300
  • Product Name:Drywall Metal Track & Stud Making Machines
  • Coil Material Thickness:0.3-0.8mm
  • Processing Material:Galvanized Steel
  • Roller Material:Cr12MOV
  • Forming Speed  :15-25m,Min
  • Shaft Material:45# Steel
  • Transport:Chain Transmission
  • Roller Station:12 Stations
  • Transport Package:Plastic Film
  • Specification:50-75-100
  • Trademark:Nexus Machinery
  • Origin:Cangzhou
  • HS Code:8455221000
  • Production Capacity:10

Description

No.

Item



1.

Processing Material

PPGI,GI

2.

Processing Thickness(mm)

0.5-1.6 mm

3.

Material of Rollers

45# steel, with hard chrome coated

5.

Diameter of Shaft

40mm

6.

Production Speed

0-25m/min

7.

Roller Driven

Gear Transmission

8.

Cutting Model

Hydraulic Profile Cutting

9.

Length Measurement

Encoder

10.

Control Style

PLC

11.

Operation Model

Button + Touch Screen

12.

Total Power

8kw

13.

Voltage

380V 50HZ or at buyer's request

14.

Testing Material

Q195



Drywall Metal Track & Stud Making Machines

Drywall Metal Track & Stud Making Machines
Drywall Metal Track & Stud Making Machines

1. How long the machine could be made?- Normally speaking, light gauge steel frame machine could
be made without 45 working days. If you need machines in a hurry, we can make it for you
less than a month.
2. How to visit your company?
-a.Fly to Beijing airport:   By high speed train From Beijing Nan to Cangzhou Xi (1 hour),
then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5
hours), then we can
pick up you.
3. Do you have after sales support?
-Yes, we are happy to give advice and we also have skilled technicians available across the
world.We need your machines running in order to keep your business running.


Cangzhou Nexus Machinery Co., Ltd is the manufacturer specialized in various cold forming

machineries and automatic production lines. Main products are:

        1.  roofing/wall panel roll forming machines,

        2.  tile roll forming machines,

        3.  C/U/Z purlin roll forming machines,

        4.  floor decking roll forming machines,

        5  steel frame truss roll forming machines,

        6. Drywall Metal Track & Stud Making Machines

        7. customerized machines.  (OEM and ODM)

       In recent years, our products at large scales have been sold to more than 50 countries and regions, Thailand,India,Malaysia,Turkey,Saudi Arabia, Russia,Albania,Armenia,the United States, Grenada,Bolivia,Colombia,Chile,South africa,Kenya, Tanzania,Egypt and etc, and has won the universal appreciation and commendation from the customers all over the world.
