• Model NO.：Various Model
• Output：100-1500tpd
• Experiences：50 Years
• Condition：New
• After Sale Service：for The Whole Using Life
• Spare Parts：We Offer
• Testing：We Offer
• Type：Cement Clinker Grinding Station
• Training：on Site
• Transport Package：Standard Export Packing
• Specification：50-3000tpd
• Trademark：ZK
• Origin：China

Capcity

25t/d

50 t/d

100 t/d

150 t/d

200 t/d

Rotary kiln

Specification

Φ1.4×33m

Φ1.6/1.9×36m

Φ2.2×45m

Φ2.5×50m

Φ3×60m

Capacity

1t/h

2t/h

4t/h

6t/h

8t/h

Calcination

Temperature

(ºC)

1450

1450

1450

1450

1450

Raw mill

Specification

Φ1.2×4.5m

Open circuit

Φ1.5×5.7m

Open circuit

Φ1.83×6.1m Open circuit

Φ1.83×6.1m

Closed circuit

Φ2.2×6.5m

Closed circuit

Capacity

1.7t/h

4.5t/h

9t/h

12t/h

16t/h

Motor power

55kW

130kW

210kW

210kW

310kW

Cement mill

Specification

Φ1.2×4.5m Open circuit

Φ1.5×5.7m

Open circuit

Φ1.83×6.1m Open circuit

Φ1.83×6.1m

Closed circuit

Φ2.2×6.5m

Closed circuit

Capacity

1.4t/h

3.5t/h

6.5t/h

8t/h

12t/h

Motor power

55kW

130kW

210kW

210kW

310kW

New dry process cement production line(300-1500t/d) configuration

Capacity

300t/d

700 t/d

1000 t/d

1500 t/d

Pre-heater

   C1

2-Φ2500

Φ3500

Φ4800

2-Φ4000

C2

Φ3600

Φ4800

Φ4800

Φ5800

C3

Φ3600

2-Φ3700

Φ5200

Φ5800

C4

Φ3600

Φ4800

Φ5200

Φ6200

C5

Φ3600

Φ4800

Φ5200

Φ6200

Pre-calciner

Specification

Φ2200

Φ2800

Φ4800

Φ5200

Rotary kiln

Specification

Φ2.8×44m

Φ3×48m

Φ3.2×50m

Φ3.5×54m

Capacity

12.5t/h

30t/h

42t/h

63t/h

Calcination temperature (ºC)

1450

1450

1450

1450

Raw mill

Specification

Vertical roller mill

Φ1700

Dry mill

Φ3.2×7+1.8m

Dry mill

Φ3.5×10m

HRM2800

Vertical roller mill

Capacity

30t/h

50t/h

85t/h

130~160t/h

Introduction to Cement Clinker

The cement clinker uses limestone and clay iron raw materials as the primary raw supplies based on an proper proportion of preparing raw, cooked to some or all the molten, and upon cooling and semi-finished products. Within the cement industry, the most typical silicate cement clinker major chemical composition of calcium oxide, silicon dioxide along with a smaller quantity of aluminum oxide and ferric oxide. Silicate cements clinker with right amount gesso common ground, i.e. Portland cement.

Clinker grinding system introduction:

The grinding system adopts two ball mills. Clinker, gypsum and additives are ground in a ball mill. Pozzolan is ground in another ball mill. In this way, pozzolan powder fineness will be good. If clinker and pozzolan are ground together, it will be difficult to meet the required fineness due to the pozzolan having a high Moh's value of 7-9. So that it will affect the final cement quality.

Our service:

Optimum Service of ZK CORP:


We have advanced production technology and management. Our professional engineers and after-sales groups can offer optimum service for our customers.

Pre-sale services

Act as a good adviser and assistant of you; enable you to get rich and generous returns on your investments;

1. Select equipment model; 2. Design and manufacture products according to clients' special requirement; 3. Train technical personnel for clients

Services during the sale

Respect your requirement; devote ourselves to improving the total value of yours.

1. Pre-check products before of delivery; 2. Help you to draft solution.

After-sales service

Provide considerate services to minimize your worries.

1. Assist you to prepare for the first construction scheme; 2. Install and debug the equipment; 3. Train the first-line operators on site; 4. Examine the equipment regularly; 5. Take initiative to eliminate the troubles rapidly at site; 6. Distribute the guarantee fittings door-to-door; 7. Provide perfect service; 8. Provide technical exchanging; 9. Provide maintenance for big items.

 Quality assurance

We have got

ISO9001:2008 Quality Management System Certification

CE Certification (Ball Mill)

ISO14001:2004 Environmental Management System Certification

OHSAS 18001:2007 Occupational Health & Safety Management System Certification

Company infromation:

Henan Zhengzhou Mining Machinery Co., Ltd is located in Wulong Industrial Park of Zhengzhou Xingyang which is the capital of Henan Province. It is at the junction of 310 State Road and Xingmi Road, close to the highway, railway station, West Zhongyuan Road, downtown area of Zhengzhou and Zhengzhou International Airport. The transportation condition is very convenient. The main products of company include: ball mill, rotary kiln, vertical preheater, cooler, crusher, metallurgical coke oven, magnetic separator, flotation machine, classifier, feeder, bucket elevator, preheater, dust collector, elevator, drier, and other equipments relate to metallurgy, cement, lime, mineral processing, refractory, chemical industry.
