Roll Forming Machine for Yx67-490 Lockseam Profile
XIAMEN FUMING ROLL FORMING MACHINERY CO., LTD.- Tile Type：Gi, PPGI, Colored Steel
- Certification：CE, SGS
- Condition：New
- Customized：Customized
- Usage：Roof
- Transmission Method：Gear,Sprocket, Gear Box or Toroidal Worm Box
Base Info
- Model NO.：YX67-490
- Color：Customized
- Thickness：0.4mm-0.8mm
- Effective Width：835mm
- Warranty：12 Months
- Transport Package：Container
- Specification：40GP
- Trademark：FUMING
- Origin：Xiamen
- HS Code：8455229090
- Production Capacity：15 Sets,Month
Description
ROLL FORMING MACHINE FOR YX67-490 LOCKSEAM PROFILEDrawing
Material Specification Thickness 0.4mm to 0.7mm Effective width 490mm Feeding width Approx.610mm Material PPGI, GI Yield strength 300MPa Machine Components 5Ton*1250mm Hydraulic Decoiler Coil inner hole expanding Hydraulic system, 3KW pump motor Speed regulating Frequency inverter, 3KW motor Expanding type Taper wedge expanding system Load capacity Max.5Tons Coil inner-diameter 510±30mm Coil outer-diameter 1600mm Coil width Max.1250mm Stop/start rotation Automatic stopping device with limited switch to assist Option Please refer to Decoiler on home page Roll Forming Machine Driving system Gear/sprocket Option for driving system Gear box or toroidal worm box Forming station 14 stations Roller material 45# steel, CNC lathes, hard chrome coated Option for roller material Cr12, Cr12Mov Shafts diameter Ø75mm Main motor 7.5KW, frequency speed control Line speed of rollformer Approx. 18m/min or customized Hydraulic Cutting Device Cutting type Slug breaker Cutting tool material Cr12, heat treatment Hydraulci pump motor 4KW PLC Control System Function Control quantity and cutting length automatically PLC Siemens Touch screen Siemens Inverter Schneider or Delta Encoder Omron Cut-to-length tolerance ≤±2 mm or customized Control Voltage 24V Product Rack Un-powered, three units Electrical Seamer 1 unit Hand Seamer 2 units
