• Model NO.：CLJZ2X-500*4200
• Power Supply：380V,50Hz
• Air Pressure：0.5~0.8MPa
• Cutting Motor Power：2*2.2kw
• Motor Rotary Speed：2800r,Min
• Air Consumption：60L,Min
• Blade Specification：500*30*4.4 Z=120
• Cutting Length：360-4200mm
• Cutting Width*Height：150*200mm
• Cutting Angle：90 45 Degree
• Overall Dimension：5700*1750*1950mm
• Weight：About 1800kg
• Usage：Aluminum Window Making Machine
• Servise：One Year Warranty
• Transport Package：Wooden Box
• Specification：digital display aluminum double head cutting saw
• Trademark：TRUEPRO
• Origin：China
• HS Code：8461500090
• Production Capacity：500sets,Year

Power supply
 380V/50HzCutting motor power
 2*2.2kW Motor rotary speed
 2800r/minAir pressure
 0.5~0.8MPaAir consumption
 60L/minBlade specification
 500×30*4.4 Z=120Cutting length
 max 4200mm min 360mm at90 degreeCutting width*height
 max 150mm*150mm at45  max 150mm*200mm at90Cutting angle
 90 45 degreeOverall dimension
  5700*1750*1950mmWeight
  about 1800kg

Machine Configuration:

Saw blade
 WagenSolenoid valve
 Germany FESTOCylinder

JPC(FESTO Joint Venture Brand)

Motor

Simens

Air Filter Device

STNC

Electrical Button and Switcher

Schneider

Linear Bearing System

HIWIN

Magnetic Grid

SIKO

Jinan Truepro is a manufacturer of window machine, insulating glass processing machine and curtain wall machine with
well-equipped testing equipment and strong technical force. With a wide range, good quality, reasonable prices and stylish
designs, our products are extensively used in building trade and other industries. Hope we can cooperate with you.
We believe that "IT'S THE BEST THAT FITS MOST."
Every machine could be customized to meet your special requirement.





1. When can we arrange shippment?
We usually arrange shippment within 15 days after getting deopsit,
but customized machines should be more than 25 days.

2.What you can do if my machines have problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines

3.Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation
training. All of our engineers have passport.

4. If I make Aluminum window and door, how many basic machines do i need?
1)double head cutting saw
2)Lock hole copy milling machine
3)End milling machine
4)Automatic Corner connector automatic cutting saw
5)Single head Corner combining machine
