• Model NO.：DX-686
• Thickness of Sheet：0.3-0.8mm
• Hydraulic Pump Station：4kw
• Control System：PLC
• Voltage：380V
• Motor Power：5.5kw
• Cutting Head：Cr12
• Shaft：75mm
• Roller：45# Steel
• Material：Galvanized,Aluminium,Color Steel Sheet
• Machine Name：Usage of Roll Forming Machine
• Transport Package：Nude, Covered with Plastic Film
• Specification：CE, SGS
• Trademark：DIXIN
• Origin：Botou, Hebei, China
• HS Code：84552210
• Production Capacity：30 Sets,Month

No.Main parameter for Usage of roll forming machine1Suitable to processGalvanized/Aluminum/Color steel sheet2Width of plate1250mm3Thickness of plate0.3-0.8mm4RollersHigh grade 45# steel, with hard chrome plating5Forming steps166Sprocket chain1.5 inch7Pump station power4kw8Shaft75mm, high grade 45# steel, heat treatment9Hydraulic oil pumpCB-E31010WeightAbout 5.0 tons11Productivity8-12m/min12Cutting headCr12 mould steel with quenched treatment13Control systemTAIDA brand PLC control14Voltage380V 3Phase 60Hz15Motor power4kw16DimensionAbout 6.8m*1.5m*1.5m17Hydraulic pressure10-12mpa18Index error of length±1mm19The temperature range of working line-35-50°
4. Want a free quotation for make budget?
Just send inquiry to me now!
5. We are your reliable partner!
We always do the best to make our machine perfect in every detail part.
Any pics or videos about machine, we can provide you.
6. Payment terms
30% T/T as the deposit when contract signed, 70% balanced before shipping.
