• Model NO.：688
• Transport Package：Main Machine Nude Packing with Plastic Film
• Trademark：14*1.4*1.25m
• Origin：China
• Production Capacity：150platform,Year

Basic Info.

Model NO. 688 Transport Package Main Machine Nude Packing with Plastic Film Trademark 14*1.4*1.25m Origin China Production Capacity 150platform/Year

Product Description

Product brief introduction

1. Adopt synchronous pressure, 24 rows of shaft forming, flat plate surface, no wrinkle, no painting phenomenon.

2. The fuselage is welded with 450mmH steel and the middle plate is welded with 18mm steel.

3. The shaft USES 45# steel; the processing rear shaft body size ∅95mm; the mold wheel USES 45# steel for processing and forming; the surface is plated with hard chromium; quenching treatment.

4. The drive adopts 2-inch sprocket wheel and chain drive (external mounted), and 2 8#11Kw planetary cycloidal reducer, with smooth movement and no noise.

5. The middle plate is connected with cast iron pull plate to ensure that the machine does not deform when working.

6. The transmission bearing adopts high-quality 213 high-speed double-sealed bearing, which is maintenance-free to extend the machine life.

7. The shearing hydraulic system adopts the cdf-10 gear pump, the motor power is 4Kw, the noiseless operation is smooth, the service life is long, the shearing adopts the middle plate welding double cylinder and the heavy duty.

8. The computer control system adopts PLC frequency converter control system with high intelligent industrial electronic programmer. The operation is simple, the accuracy is accurate, the performance is stable, the length precision is less than 2mm, and the plate speed is 6-12m/min.

9. Apply 0.3mm-1.6mm color coated board or galvanized board.

10. The weight of the equipment is about 13T, the length of the machine is about 14m, the width is 1.4m, the height is 1.25m, and the plate speed is 8-14m/min.



Shipping & Packing

Hebei Kexinda Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.

     Strong technical resources are the most stable guarantee for our products' quality. We adopt computer software for design drawing, production drawing and installation drawing for steel construction equipment. We adopt advanced computer digital inspection and produce high quality light steel structure equipment. Our technical is updating day by day !

     Our sales network covers all over China. We also sell products to the United States, Australia, the Netherlands, Germany, Ecuador, Bolivia, Thailand, Malaysia, Indonesia, India, the Philippines, Bangladesh, Nigeria, South Africa, Ethiopia, Syria, Libya, Ghana, Sudan, Saudi Arabia, the United Arab Emirates, Turkey, Azerbaijan and other markets.

     Our company has matured after-sale service network, we could provide efficient and satisfactory service for you throughout the period of our cooperation.If necessary, we can supply you with local technical support and send technicians to for installation and operation training.





 Customer Visit And Exhibition

 FAQ

1.How to play order :

Inquiry---confirm the profile drawings and price---confirm the PI---arrange the deposit or L/C---then OK

2.How to visit our company :

Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi(1 hour),then we can pick up you.

Fly to Shanghai Airport:By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5hours),then we can pick up you.

3.When we exported the machines :

We have beening making and exporting the machines since from the year of 1998.

4.*Guarantee* :

Lifetime maintenance guarantee.If some part of the machine is broken.We will supply the best original parts for the machine from our own factory. If the parts are damaged due to improper operation, buyer will pay for the freight.


5.*After-sales* :

To give you the best after-sales service, the first give you video call with professional technicians , the second we send technicians to your country to repair the machine,
The buyer shall bear all expenses, including visa, round-trip airfare and suitable accommodation, and pay the salary of usd 100 / day.

6.Contact us:

If you want to get more pictures or videos of the machines, feel free contact us.
We will give you the best experience!
