• Model NO.：QTY9-18 Hydraulic Automatic Block Making Machine
• Hollow Block Production Capacity：9PCS,Mould
• Road Brick：1056m2,8 Hours
• Road Brick Production Capacity：0.6m2,Mould
• Cycle Time：15-18s
• Power：Power42kw
• Dimensions：3010*2600*2950mm
• Bamboo Pallet Size：1280X600mm
• Personnel Quota：Personnel Quota 6 People
• Transport Package：Export Wooden Packing or as Required
• Specification：QTY9-18 Hydraulic Automatic Block Making Machine
• Trademark：FOCUS
• Origin：Zhengzhou, China
• HS Code：8474802000
• Production Capacity：60 Sets Per Month

Basic Info.

Model NO. QTY9-18 Hydraulic Automatic Block Making Machine Hollow Block Production Capacity 9PCS/Mould Road Brick 1056m2/8 Hours Road Brick Production Capacity 0.6m2/Mould Cycle Time 15-18s Power Power42kw Dimensions 3010*2600*2950mm Bamboo Pallet Size 1280X600mm Personnel Quota Personnel Quota 6 People Transport Package Export Wooden Packing or as Required Specification QTY9-18 Hydraulic Automatic Block Making Machine Trademark FOCUS Origin Zhengzhou, China HS Code 8474802000 Production Capacity 60 Sets Per Month

Product Description

Qty9-18 Hydraulic Automatic Block Making Machine, Block Production Line


∑Advantage in technology
1. FOCUS brick making machine are produced according to the international standard, which have also reached advanced national standards. Technology such as constant vibration, frequency conversion and braking is put into practice in the production process. Apart from this, it can eliminate the redundant cibration and energy consumption immediately.

2. Key parts of the equipment are made with fine workmanship according to fatigue-resistant design, which may meet users' demand of continuous multi-shift production.




∑Features of brick making machine
1.Omnibearing vibration of table and mold improves the density of bricks. In order to get even transmission of vibration force, two-way mode is adopted in the lower vibration with two vibration tanks linked to each other by two hydraulic motors.

2.The material feeder equipped in our brick making machine with a spiral reticulation structure distributes materials evenly, which shortens the operation time and then the mold cycling time.

3.Due to its multi-function and advanced technology, FOCUS brick making machine can be applied to produce various types of concrete blocks, standard bricks, perforated bricks and paving bricks. These products are of good quality, high compression strength and accurate dimension. Besides, more types can be produced such as color paving bricks, color grassland bricks and curb bricks if the secondary distributing device is added to the line.

4.The main frame of FOCUS brick making machine is wide for the convenience of mold filling, so more blocks can be made. In order to get even pressure, three oil reservoirs are used, which raise the pressure to as high as 100t. Moreover, the smallest reservoir in the middle increases the operating speed of the left and right ones respectively, thus improving the productivity.

5. FOCUS brick making machine is applicable to sand, stone chips, slag, coal dust, fly coal ash, furnace slag and construction waste etc.

6. FOCUS brick making machine equipped with an integration of mechanism, electronics and hydraulics is automatically controlled by the PLC computer, which supervises every phase through the whole course. Once fault is detected, the machine can lock itself. Meanwhile, output statistics is produced by the computer. Thus, it holds a leading position for its outstanding performance in terms of environmental protection.



∑Technical Indexes of FOCUS brick making machine

Production Capacity	Hollow brick 390*190*190mm 9pcs/mould Standard brick 240*115*53mm 50pcs/mould Road brick 0.6m2/mould
Cycle time	15-18s
Shift output	Hollow brick 390*190*190mm 14400pcs/8 hours Standard brick 240*115*53mm 80000pcs/8 hou Road brick 1056m2/8 hours
Vibrating force	80KN
Power	42KW
Weight	13.5T
Dimensions	3010*2600*2950mm
Bamboo pallet size	1280x600mm
Land area:	10,000 m2, including(Workshop: 500 m2, Warehouse: 800 m2, Office: 100 m2, Space: 8,600 m2)
Power	General power: 85KW  Mean power: 50KW
Personnel quota:	6 people

The test result from the State Building Materials Test Center shows that all the technical indexes of products made by FOCUS brick making machine have reached the national standards.

According to the local materials, resources and different application of products, various strength grades demanded by the designer can be made, such as 1.5Mpa, 2.5 Mpa, 3.5Mpa, 5.0Mpa, 7.5Mpa, 10.0Mpa,15.0Mpa, etc. in the methods of assumed unit weight, overweight substitution, empirical formula, etc. on the basis of the economical and practical principle.



Our FOCUS brick making machine are being purchased, installed and operated all over the world, we gained good honors from our government and quality test institute home and abroad.
- it'll be such a great honor if you can join us.
