• Model NO.：UA-48BP
• Rail：Taiwan Linear Rail
• Rack：Helical Rack
• Table：Double Layer PVC Table
• Motor：Servo Motor
• Inverter：Delta Inverter
• Pump：5.5kw , 7.5kw
• Software：Type 3 , Artcam
• Ball Screw：High Precision
• Transport Package：Plywood Box
• Specification：heavy duty type machine
• Trademark：DLM
• Origin：China
• HS Code：84609090
• Production Capacity：500 Sets, Year

UA-48BP.T:  Nesting Solution With Automatic Loading and UnloadingCompositionAutomatic loading lift, Material feeding system, Dust absorption structure, Accurate positioning structure,
Smart cutting machining centre, Unloading belt machine, High efficiency vacuum pump, PC version control cabinetWorking area1250X2500X250(mm)Travelling speed70 m/min(MAX)Cutting speed20 m/min(MAX)Spindle parametersHSD air cooling 9.5KW 24000rpmController OSCustom SYNTEC system with PCDriving systemXY:850W Yaskawa servo  Z:850W Yaskawa brake servoWorking VoltageAC380V/3PH/50HZElectrical accessoriesTaiwan Delta VFD / French Schneider Low voltage electrical components / high quality cableDriving partsGerman HERION pinion/Taiwan PMI rail/Taiwan PMI ball screwTable StructureDouble layers of multi-point high efficient vacuum absorbable countertopSize9000*2000*2200(mm)Cooling systemElectronically controlled coolingLubrication systemAutomatic lubrication systemTool setting gaugePrecision tool setting gaugeAccessories17.5KW Vacuum pump1 set27.5KW double canister dust collector1 set3Tool box(including tools)1 set4ER32 spring collet 1/24 pcs5Cutting tool4 pcs6Table vacuum plug120 pcs7High quality φ10 sponge rubber seal10m8Documents1 copy
