50, 100, 150, 200 Ton Bolted Cement Silo

Zhengzhou Focus Machinery Co., Ltd.
  • Certification：CE, ISO9001: 2000
  • Type：Cement Production Machinery
  • Condition：New
  • Machining Process：Vacuum
  • Cement Storage Volume：100t,200t,300t
  • Cement Silo Type：Bolted,Flaked,Pieces,Sectional,Detachable

Base Info

  • Model NO.：100t
  • Average Thickness：6-8mm
  • Cement Silo Diameter：2.5m,3m,3.5,3.8,4.1m
  • Cement Silo Height：8.7,11.4,11.8,13,14.5m
  • Total Height：16,18,20.3,22,22.8m
  • Matched Mixer：Js500,750,1000,1500,2000,3000,Sicoma Mixers;
  • Transport Package：Standard Packing for International Transport
  • Specification：ISO CE certified
  • Trademark：FOCUS cement silo
  • Origin：Henan Zhengzhou
  • HS Code：8479899200
  • Production Capacity：100 Sets Per Month

Description

Basic Info.

Model NO. 100t Average Thickness 6-8mm Cement Silo Diameter 2.5m/3m/3.5/3.8/4.1m Cement Silo Height 8.7/11.4/11.8/13/14.5m Total Height 16/18/20.3/22/22.8m Matched Mixer Js500/750/1000/1500/2000/3000/Sicoma Mixers; Transport Package Standard Packing for International Transport Specification ISO CE certified Trademark FOCUS cement silo Origin Henan Zhengzhou HS Code 8479899200 Production Capacity 100 Sets Per Month

Product Description

Q235 Steel 100 ton Bolted Cement Silo with factory price:
Sizes of FOCUS Cement silo:
Integral type cement silo:50ton welded cement silo, 50ton complete cement silo, 50ton whole piece cement silo, 50ton undetachable cement silo
Bolted type cement silo:50t bolted cement silo, 60t bolted cement silo, 100t
bolted cement silo,150t bolted cement silo,200t bolted cement silo,300t bolted cement silo,500t bolted cement silo.
Description of  FOCUS cement silo?
FOCUS cement silo is a kind of closed huge column-shape tank storing bulk materials. The cement silo is suitable for storing bulk materials such as grains, cement, powder and fly-ash. Material level system is installed in the silo, which can show the position and quantity of the materials. The arch-breaking equipment can clear up hard materials from long time sediment. The materials can be sent to all the positions with the combination of cement silo and screw conveyor pump. Easy installation with its characteristics of safety and reliability make it an ideal cement bin for the concrete mixing plant. 30T, 50T, 80, 100T, 150T, 200T,300T,500T detachable and whole piece cement silos can be chosen according to clients' requirements.
50, 100, 150, 200 Ton Bolted Cement Silo
50, 100, 150, 200 Ton Bolted Cement Silo50, 100, 150, 200 Ton Bolted Cement Silo

Model
Silo diameter
Silo height
Total height
Matched mixer
Matched screw

50T
2.5m
8.7m
16m
JS500/JS750/JS1000
LSY219/LSY273

100T
3m
11.4m
18m
JS1000/JS1500/JS2000
LSY219/LSY273

150T
3.5m
11.8m
20.3m
JS1000/JS1500/JS2000/JS3000
LSY273/LSY325

200T
3.8m
13m
22m
JS2000/3000/MAO3000/2000/MAO4500/3000
LSY273/LSY325

300T
4.1m
14.5m
22.8m
JSseries/MAO4500/3000/MAO6000/4000/MAO7500/5000
LSY325
