• Product Name：Metal Roll Forming U C Z Purlin Machines
• Coil Material Thickness：1--3mm
• Processing Material：Galvanized Steel
• Roller Material：Cr12MOV
• Roller Station：12-18 Stations
• Driven：Chain Transmission
• Forming Speed：10-15m,Min
• Punching Type：Hydraulic Punching
• Cutting Type：Hydraulic Post-Cutting
• Operation Type：Touching Screen
• Transport Package：Plastic Film
• Specification：80-300
• Trademark：Nexus Machinery
• Origin：Cangzhou
• HS Code：8455221000
• Production Capacity：10

1.

Configurations

Manual Uncoiler, Guiding Platform, 9 Shaft Strip Leveler,  Main Machine Of Roll Forming, Hydraulic Motor, Pre-Punching Device,Pre-Cutting Device, Hydraulic Station, PLC Control, Supporter Table.

2.

Control System

PLC  Inverter  Encoder   Touch Screen

3.

Main Frame

400mm H-Beam

4.

Total Power

22 kw

5.

Power Supply

380V, 3-Phase,50Hz

6.

Forming Speed

12-24m/min

7.

Roll Station

18 stands

8.

Roller Diameter

80mm

9.

Effective Width

80-300mm

10.

Feeding Thickness

1.5-3.0mm

11.

Backboard Thickness

20mm

12.

Cutter Standard

GCr12

13.

Roller Standard

Gcr15#

14.

Overall Size

About 8500×1000×1400mm

15.

Total Weight

About 10T

16.

Custom

According to customer's requirements

NOTE: All technical parameters can be changed according to user s need, and only as a reference.

2.Metal Roll Forming U C Z Purlin Machines Components specification

(1) Manual Uncoiler

Max.Capacity:5T

(2)Pre- Cutting Device& Pre-Punching Device

It adopts hydraulic motor drive and PLC computer-controlled to fix length of die cutting.

Cutting length tolerance:±2mm

Material:GCr12 with quenched treatment 60-62°C

(3)Hydraulic System

Match equipment: Electro motor, a set of hydraulic tank, a set of hydraulic oil pump, and electromagnetic valve.

Power: 22 KW

(4)Control System

It adopts PLC control system, Color Touch Screen; the target length can be adjusted by it.

Computed mode: automatic or manual

(5)Encoder

The counter gauges length, and modulates pulses.

(6)Simple Stack

It is used for loading the formed plate.
