Commercial Metal Roof Trapezoidal Roll Forming Machine
Cangzhou Dixin Roll Forming Machine Co., Ltd.- Tile Type：Colored Steel
- Certification：CE, ISO, Pbr Roll Forming Machine
- Condition：New
- Customized：Customized
- Usage：Roof, Wall, Floor, Pbr Roll Forming Machine
- Transmission Method：Machinery
Base Info
- Model NO.：Trapezoidal Roll Forming Machine
- Product Name：Pbr Roll Forming Machine
- Control System：PLC Computer
- Coil Width：1250mm
- Sheet Thickness：0.3-0.8mm
- Pump Power：4kw
- Main Moter Power：5.5kw
- Middle Plate：16mm
- Chain：1 Inch
- Roller：High Grade 45# Steel
- Thickness of Plate：0.3-0.8mm
- Transport Package：Nude, Covered with Plastic Film
- Specification：CE, SGS
- Trademark：DIXIN
- Origin：Botou, Hebei, China
- HS Code：84552210
- Production Capacity：30 Sets,Month
Description
1.Suitable material
Color steel sheet , galvanized steel sheet,aluminum sheet
2.Installation Dimension (L*W*H):
3.Main motor power
4KW with Cycloidal reducer
4.Hydraulic station power
4KW
5. Hydraulic oil pump
CB-E 310
6.Thickness of material
0.3mm~0.8mm
7.Diameter of principal axis
Φ70-90mm
8.Material expand width
1000,1200,1250mm
9.Electric tension
380V 3phase 50HZ or as the customer's requirements
10.Material of roller
High grade 45# forged steel plated with hard chrome plating
11.Controlling system
PLC
12.Processing speed
8-12m/min
13.Processing precision within
1.00mm (depend on design)
14.Material of cutting blade
Cr12 mould steel with quenched treatment
15.Kind of drive
0.6 inch chain link bearing model 6210
16.Roller station
8-20 Rollers
17.Roller material
high grade 45#steel; Cr12 quenching
18. Leak frame load-bearing
2.5 T
Why choose us ?
Advanced machinery, well trained workers.
More than 12 years experience in roll forming machine Ad industry.
Unique designed, good quality, competitive price.
Full range of roll forming machine solution.
How do order?
How is the payment ?
T/T( 30% by T/T in advance, the rest 70% to be paid by T/T after you inspect the Product in seller's factory before delivery )
Customers
Our machine exported all over the world,so our customers are also from all over the word.
Sometimes some customers visit our factory before placing orders, some customers when theirs machines finished ,the come to check test machine, we also have some customers come to our factory to learn how to operate the machine.
FAQ
1. Q: How to visit our company:
A: Fly to Beijing Airport: By fast train From Beijing South station to Cangzhou west station
(1hour), then we can pick up you to factory(40min).
Fly to Shanghai Airport: By fast train From Shanghai Hongqiao station to Cangzhou west
station(4.5 hours), then we can pick up you to factory(40min).
2. Q: What should I provide if I want to customized machine?
A: U need provide profile drawing, material, thickness, voltage and your special requirements.
3. Q: What is the Warranty?
A: Within 12 mounts, all technicals are ready to serve you at any time.
4. Q: What can you do if the machine broken?
A: Our machine's warranty period is 12 months, if the broken parts can't repair, we will send
new parts replace the broken parts free, but you need pay the express cost if after warranty period. we can negotiate to solve the problem, and we supply the technical support for whole life of equipment.
5. Q: If need technician to workshop to debug and teach, how to do?
A: We sent technician to your country to fix the machine. Buyer should bear cost including: visa, round trip ticket and suitable accommodation, also buyer should pay the salary 100 USD/day.
