• Model NO.：CJLZK-1800
• Air Pressure：0.5-0.8MPa
• Drilling Diameter：1-7mm
• Input Power：3kw
• Air Consumption：30L,Min
• Process Dimension：300*2000mm
• Min Hole：Water Slot Milling Machine
• Weight：300kg
• Transport Package：Standard
• Specification：3100*1200*960mm
• Trademark：Truetec
• Origin：China
• Production Capacity：15sets,Month

Basic Info.

Model NO. CJLZK-1800 Air Pressure 0.5-0.8MPa Drilling Diameter 1-7mm Input Power 3kw Air Consumption 30L/Min Process Dimension 300*2000mm Min Hole Water Slot Milling Machine Weight 300kg Transport Package Standard Specification 3100*1200*960mm Trademark Truetec Origin China Production Capacity 15sets/Month

Product Description

Combination Drilling Machine for Aluminum Profile


Detailed Information:


 Eqipment Advantages
1. It used for drilling hinge installing hole, sliding support hole and four connectingrod hole of aluminum window and door profile (outward window and tilt Windows, etc).
2.It can process on both sides of total 8 holes at one time. machining efficiency is very high.
3.It used of high precision multi axis drilling package from -Taiwan to ensure machining accuracy and service life.
4.Foot switches control action, easy to operate.
Technical Parameter

Brand Name	Truepro	Air pressure	0.5-0.8MPa
Model	CJLZK-1800	No.of power drill	8
Input power	1.14kw	Motor rotary speed	25000r/min
Power supply	380V 50Hz	Process dimension	300*2000mm
Drilling diameter	Φ1-7mm	Min hole distance	22mm
Max hole distance	380mm	Spindle speed	1400rpm
Overall dimension	1200*1200*1800mm	Weight	300kg

Machine processing

We work with everything from raw material to final machine, could guarantee machine quality from each step. select each part carefully, we are strive to quality first when machine production and test each machine before delivery.
We will provide the best machine for you.



Packing & Delivery

Certifications

ISO9001/2000 International Quality Certification
CE Certification
Most advanced technology and high level configuration
Personalized service and perfect after-sale service


Company Information



Our Service

Pre-sale service

Free contact for the most suitable machine
Free professional design for each customer especially.

After sale service

24 hours technical support by phone, email or skype
1years warranty period
Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.

PaymentP

L/C, 30% deposit by T/T,70% spare payment L/C.
T/T, 30% deposit by T/T,70% spare payment before shipment.
Western Union or Paypal.

FAQ

1. When can we arrange shippment?
We usually arrange shippment within 15 days after getting deopsit,
but customized machines should be more than 25 days.

2.What you can do if my machines have problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines

3.Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passport.

4. If I make Aluminum window and door, how many basic machines do i need?
1).double head cutting saw
2).Lock hole copy milling machine
3).End milling machine
4).Automatic Corner connector automatic cutting saw
5).Single head Corner combining machine
