Light Steel Keel Making Machine for Earthquake Resistance Building Houses
Xiamen Xinhonghua Machinery Co., Ltd.- Warranty：1 Year
- Certification：CE, ISO9001
- Customized：Customized
- Condition：New
- Control Type：PLC
- Automatic Grade：Automatic
Base Info
- Model NO.：c89-5s
- Machine Color：Green or as Your Request
- Name：Light Gauge Steel Roll Forming Machine
- Hydraulic Power：5.5kw
- Material Width：174mm
- Height of Roofing：38mm
- Voltage：380V,50Hz,3pH
- Control System：PLC(Imported Brand)
- Material Thickness：0.7mm-1.2mm
- Effective Width：89mm
- Speed：25-30m,Min
- Transport Package：Standard Packed for Export
- Specification：SGS
- Trademark：XHH
- Origin：Fujian, China (Mainland)
- HS Code：8455229090
- Production Capacity：10sets,Moth
Description
Size
3700*800*1100mm
Weight
2800KGS
Main Servo Motor Power
5.5KW
Hydraulic Motor Power
5.5KW
Forming Steps
10+2steps for reshaping
Processing Speed
Voltage
380V/50HZ/3PH
Lip of C Profile
10mm
Tolerence Of Forming
0.75mm
Forming Thickness
0.7-1.2mm
Height
38mm
2)Main Accessories:
(1) .Main Forming Machine;
(2) .Hydraulic Strip Uncoiler;
(3) .Hydraulic Punching Device;
(4) .Hydraulic Motor System;
(5) .PLC Computer Controlling System With Touch Screen;
(6) .Hydraulic Forming Cutter;
(7) .Automatic Printing Device;
(8) .Design Software;
(9) .Run Out Table;
(10) .Tools;
(11) .Operation Manual.
