600-305 Arch Sheet Steel Sheet Roll Forming Machine

Yingkou Bohai Machinery Equipment Manufacture Co., Ltd.
  • Tile Type:Colored Steel
  • Certification:CE, ISO
  • Condition:New
  • Customized:Customized
  • Usage:Roof
  • Transmission Method:Machinery

Base Info

  • Feeding Width:600mm
  • Effective Width:305mm
  • Step of Rollers:14 Steps
  • Controlling System:PLC&Manual
  • Material of Cutting Blade:Cr12 MOV
  • Material of Roller Shaft:45# Steel, Galvanized
  • Material of Rollers:45# Steel, Quenched with Hard Chrome
  • Type of Cutting:Roll-Formed and Length-Set Cutting
  • Proper Span:3-26m
  • Transport Package:Packed in Container
  • Specification:8900mm*2230mm*2300mm
  • Trademark:BOHAI
  • Origin:Liaoning Province of China
  • HS Code:8455229090
  • Production Capacity:20 Sets,Year

Description

Production NameBohai Arch Roof Roll Forming MachineSize8900mmX2100mmX2300mm(With Single Axle 4 Tires)Total WeightAbout 10 TonThickness of Bending Leaf10mm Thickness, Processed by CNCCutting Blade12CrMov Material, Heat TreatmentCutting TypeMechanical CuttingForming TypeRoll-Formed and Length-Set CuttingPowerTotal Motor Power: 15.2KW
Roll Forming Motor Power: 5.5KW
Cutting Power: 3.0KW
Bending Power: 3.0KW+1.
5KW
Seaming Power1.1KW+1.1KWRoller Material45# High-Quality Steel, Quenched HRC 55~65, Hard Chrome PlatingShaft Material45# High-Quality Steel, GalvanizedStand of Molding13+1 StepsFeeding Width600mm Effective Width305mmUsing Rate50.8%Thickness Coil0.5-1.6mmSpeedForming Part : 15m/min
Bending Part: 13m/min
Seaming Part: 16m/min
Suitable Span4~24mDe-CoilerInner-Diameter of Coil : 450mm ~ 650mm,
Max Width of Coil : 600mm ~ 620mm
Load : 10Ton
