50tpd~1000tpd Vertical Shaft Lime Kiln
Henan Zhengzhou Mining Machinery Co., Ltd.- Application：Construction
- Certification：CE, ISO
- Customized：Customized
- Automatic Grade：Semiautomatic
- Experience：More Than 50 Years
- Design：by Professional Engineer
Base Info
- Model NO.：Various Model
- Installation：Under Our Engineer′s Guide
- After Sale Service：We Offer
- Testing：We Offer
- Maintenance：See Instructions
- Item：Lime Production Line
- Certificate：ISO9001, ISO14000
- Technical Parameters：See Technical Table
- Spare Parts：We Offer
- Transport Package：Standard Export Packing
- Specification：ISO9001, ISO14000, CE
- Trademark：ZK Brand
- Origin：Zhengzhou, China
- Production Capacity：Customized
Description
Technical Parameters Of Vertical Klin (Mixed Fuel)
Capacity(t/d)
Effective Volume
Effective Height
Effective Section
Limestone Size
Heat Consumption
CaO
Activity
(m3)
(m)
Dia.(m)
(mm)
(kJ/kg)
(%)
(mL)
100
98
20
Ø2.5
30~60/40~80
<4600
>90
>300
120
141
20
Ø3.0
30~60/40~80
<4600
>90
>300
150
202
21
Ø3.5
30~60/40~80
<4500
>90
>300
200
301
24
Ø4.0
30~60/40~80
<4500
>90
>300
300
397
25
Ø4.5
30~60/40~80
<4400
>90
>300
400
491
25
Ø5.0
30~60/40~80
<4200
>90
>300
500
735
26
Ø6.0
30~60/40~80
<4200
>90
>300
Remarks: All above data are for reference only.
Technical Parameters Of Vertical Lime Kiln (Fuel: Gas)
Capacity(t/d)
Effective Volume
Effective Height
Effective Section
Limestone Size
Heat Consumption
CaO
Activity
(m3)
(m)
Dia. or L×W(m)
(mm)
(kJ/kg)
(%)
(mL)
50
70
20
Ø2.0
30~60/40~80
<4600
>90
>300
70
80
20
Ø2.5
30~60/40~80
<4600
>90
>300
80
100
20
Ø2.5
30~60/40~80
<4500
>90
>300
100
120
20
Ø2.7
30~60/40~80
<4500
>90
>300
120
140
20
Ø3.0
30~60/40~80
<4400
>90
>300
130
150
21
Ø3.0
30~60/40~80
<4200
>90
>300
150
200
20
2.5×4.5
30~60/40~80
<4200
>90
>300
Remarks: Above data are for reference only, and suitable for Vertical Kiln which use low heat fuel. Utilization coefficient of Vertical Kiln which use high heat fuel is higher.
