• Model NO.：CSQJ-CNC-120
• Applicable Industries：Construction Works
• Operation Air Pressure：0.5~0.8MPa
• Air Consumption：60L,Min
• Input Voltage：380V,50Hz
• Input Power：1.7kw
• Main-Shaft Revolution：2800r,Min
• Profile Height：30~120mm
• Profile Width：20~120mm
• Overall Dimension：2000*1820*1500mm
• Machine Weight：700kg
• Applicable Material：PVC ,UPVC
• Function：PVC Window Making Machine
• Usage：Corner Cleaning Machine
• Service：One Year Warranty
• Transport Package：Wooden Box Package
• Specification：PVC window corner cleaning machine
• Trademark：TRUEPRO
• Origin：China
• HS Code：8479819000
• Production Capacity：500sets,Year

Model

CSQJ-CNC-120

Input power

1.7kW

Power supply

380V/50Hz

Air pressure

0.5~0.8MPa

Air consumption

80L/min

Motor rotary speed

2800r/min

Cutting width

20~120mm

Cutting height

30~120mm

Drawing groove width

3mm

Drawing groove depth

0.3mm

Overall Dimension

2000*1820*1500mm

Weight

700kg

Jinan Truepro is a manufacturer of window machine, insulating glass processing machine and curtain wall machine with
well-equipped testing equipment and strong technical force. With a wide range, good quality, reasonable prices and
stylish designs, our products are extensively used in building trade and other industries. Hope we can cooperate with you.
We believe that "IT'S THE BEST THAT FITS MOST."
Every machine could be customized to meet your special requirement.





1. When can we arrange shippment?
We usually arrange shippment within 15 days after getting deopsit,
but customized machines should be more than 25 days.

2.What you can do if my machines have problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines

3.Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation
training. All of our engineers have passport.

4. If I make PVC window and door, how many basic machines do i need?
