• Model NO.：130
• Main Frame：350h
• Transport Package：Container
• Specification：5000*1000*1600mm
• Trademark：kexinda
• Origin：Hebei
• HS Code：8455221000
• Production Capacity：3000sets

Manual Uncoiler ,Guiding Platform ,Coil Strip Leveler ,Main Machine Of Roll Forming ,Electro-Motor,Cutting Device ,Hydraulic Station ,PLC Control, Supporter Table.

Control System

PLC Delta Inverter

Main Frame

250mm H-Beam

Main Power

3 kw

Pump Power

3 kw

Power Supply

380V, 3-Phase,50Hz

Forming Speed

8-12m/min

Roll Station

14 stands

Roller Diameter

50mm

Hydraulic Pressure

10-12MPa

Forming Size

226mm

Feeding Thickness

0.3-0.8mm

Feeding Width

310mm

Backboard Thickness

14mm

Chain Size

20mm

Cutter Standard

Cr12

Roller Standard

Cr12

Cr-Plating Size

0.05mm

Overall Size

5800×1400×1500mm

Total Weight

2.5T

The metal deck forming machine is aided and optimized by computer. The metal deck produced by this machine has high strength with big wavelength.

It adheres well to concrete. Used on high buildings, it not only saves steel mold plate, but also reduces the weight of storey. With the same bearing capacity, it economizes steel and cuts down investment accordingly.

Technical parameters

1.Suitable material: Color steel panel, galvanized steel panel

2.Thickness: 0.3-0.8(mm)

3.Yield Strength: G320 (Mpa)

4.Width: 1000(mm)

5.Producing Speed: About 3(m/min)  Final product length more than 10m

6.Forming main motor power: 15.5(KW) x 5   Will be according to actual design

7.Hydraulic station power: 15.5(KW)    Will be according to  actual design

8.Uncoiler hydraulic station power: 13(KW)   Will be according to actual design

9.Uncoiler motor power: 15.5(KW)   Will be according to actual design

10.Stacker delivery system motor: 1.5(KW) Will be according to actual design

11.Pre-slit device power: 0.55(KW)  Will be according to actual design

12.Total power : 153.55(KW)      Will be according to actual design

13.Power :AC380Vï¼50Hzï¼3 Phase       According to customer

14.Dimension (L×W×H) : 47×6×2 m Will be according to actual design
