• Automatic Grade：Automatic
• Thickness：2-2.5mm
• Raw Material：PPGI,Gi
• Cutting Blade Material：Cr12
• Drive：Gearbox
• Main Frame：350h Steel
• Control System：PLC(Imported Brand)
• Total Power：50kw
• Forming Speed：1-25m,Min
• Voltage：380V 50Hz, 3 Phase
• Transport Package：in Nude, with Waterproof Cloth and Stow-Wood
• Specification：19000*1700*1500mm
• Origin：China
• HS Code：84552210
• Production Capacity：30sets,Month

                                            Main Parameter     1Length of the main part19000*1700*1500mm    2Weight of main part12 T    3Voltage380V 50HZ 3Phase    4Roller FixerGuide column    5FrameCast steel archway unit    6Frame Thickness55mm    7Drive modeGearbox    8Material of rollersCr12MOV,After rough machining, vacuum treatment HRC58-60 degrees, fine grinding holes, CNC numerical control finishing rolls, maintaining high precision and hardness of rolls    9Material of shafts40Cr   10Diameter of shafts80mm   11Number of rollers22 rollers   12Main power50kw(Cycloidal planetary gear speed reducer)



Product Features
1. More efficient and accurate execution of production orders;
2. High equipment reliability;
3. Little waste of materials and energy;
4. High productivity;
5. High quality materials, get a longer service life;
6. All parts of the machine are processed with precision, and the surface of the roll is chromeplated to ensure that customers can get qualified products at the same time, it can avoid the scratch of the color steel surface paint, and increase the service life of the roll;
7. Customized coil processing solutions to solve all aspects of technical problems.



Company Profile
Why choose Us?

• We have sold more than 3000 sets roll forming machines to many countries around the world.
• We have hundreds of models about all kinds of roll forming machine for your reference, you could't worry if you don't have a profile drawing.We can recommond you some classical models that is common in your country.
• When designing the machine, our considerate service will estimate and avoid the problem that may happen.
• One set machine can provide many solutions with different price level.But they are all the cost-effective.
• We attach importance to many details. Every machine part quality is higher than our competitors in same price level.
