Qmy4-30 Block and Bricks Machine

Shandong Shiyue Intelligent Machinery Co., Ltd.
  • Certification：CE, ISO
  • Customized：Customized
  • Automatic Grade：Automatic
  • Type：Hydraulic Shock
  • Product Name：Hollow Block Making Machine
  • Walking Type：Hydraulic

Base Info

  • Model NO.：qmy4-30
  • Color：Client Requirement
  • Vibration Frequency：2800-4500 ( R,Min)
  • Weight：2500kgs
  • Block Type：Hollow Block,Solid Block
  • Molding Cycle：25s
  • Vibration Type：Mould Vibration
  • Raw Material：Cement,Sand,etc
  • Power：9.6kw
  • Transport Package：Standard Export Package
  • Specification：2000x2100x1650
  • Trademark：SHIYUE
  • Origin：China
  • HS Code：8474802000
  • Production Capacity：5000set,Year

Description

Technical Parameters

Overall Dimension

1200*1200*1100mm

Capacity3800pcs/day

Moving methed

Hydraulic

Vibration Frequency

2800~4500 ( r/min)

hydraulic pressure16-20Mpa

Molding cycle

40 (s)

Overall Power

5.95kwshipping cycle

30s

Total Mass

960kgs

Demolding method

Hydraulic

General water consumption

5T/Day

Factory Area

500m2

Applied Products

Concrete blocks, hollow/solid blocks, pavers, interlocking blocks , curbstone,

colored pavers ,etc.

Raw Material

Crushed stone, sand , cement, dust, and fly ash, gravel, slag, and other raw

material , etc.
