Diameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year Warranty

Shijiazhuang Zhongtai Pipe Technology Development Co., Ltd.
  • After-sales Service：on-Site and Online
  • Warranty：1year
  • Pipe Material：Carbon Steel
  • Condition：New
  • Customized：Customized
  • Theory：Cold Roll Forming

Base Info

  • Application：Industry
  • Type：Pipe Mill
  • Voltage：220,380,415,420,440V
  • Raw Material：Carbon Steel,Galvanized Steel,Stainless Steel
  • Pipe Diameter：42-89mm
  • Color：Grey or as Your Require
  • Thickness：1.2-4.0mm
  • Transport Package：Container
  • Specification：Change with product customization
  • Trademark：ZTZG
  • Origin：China
  • HS Code：84551020
  • Production Capacity：200set,Year

Description

Base sheetsLow Carbon steel (δb≤500Mpa, δs≤235Mpa)Steel sheetInner diameter: Φ510-610mm Outer diameter: Max.Φ1800mmWidth of steel strip120mm-480mmThickness of steel strip1.5mm-5.0mmThe maximum weight:6.0 tonsElectricityDynamic power: AC380V±10%, 3phases, 50Hz±1.0% Control Power: AC220V±10%, one phase, 50 Hz ±1.0%Electric installed capacity:appro. 900KWCooling waterReservoir for High Frequency equipment: 30 m3, one set Reservoir for circulating cooling water: 25 m3, one setProduction capacity70000tons, according to the yearly working days, daily working hours and the products.Work speed30-90m/minPipe diameter:Round Pipe: Φ38 -Φ127mm Square Pipe: 30X30mm -100X100mm Rectangle Pipe:20X40mm -120X80mmPipe Thickness:1.5 - 5.0mm Base sheetsPipe Length:According to customers requirementsLength Tolerance:0-6



Application

1. Water pipe
2. Heating pipe
3. Low-pressure process pipeline
4. Low-pressure fire fighting a pipeline
5. Sewage Pipes
6. Steel Scaffolding Pipe
7. Wire and cable protection pipe
8. Structural support Steel Pipe
9. Industrial Steel Pipes
10. Decoration Pipe
11. Oil & Gas Pipes




Diameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyDiameter 42mm-89mm Steel Pipe Production Line 30-90m/Min 1 Year WarrantyQ:Are you manufacturer?
A:Yes,we are manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
Q:What kind of payment term do you do?
A: We do T/T and L/C.
Q:What info do you need before giving me the price and proposal?
A: Since we design individual machine based on our customer's requirement, we need your desired products' basic dimension, including all the pipe diameter(or tube length), thickness range , usage, raw material steel grade, coil weight, and degree of automation.
Q: What should I do if I just start a new business?
A:Contact us immediately ,we provide free consultant for pre-sales service .Also we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
Q:How do you do QA?
A:We have special team to do strict QA,this is one of our strengths:
(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.(2)Every shaft will be inspected for the centering jumpiness.
(3)Every roller will be checked to make sure its in the range of tolerance critical parts will be inspected for all dimensions.
Q:Why I should choose you? what are the differences between you and other Chinese suppliers?
A:We are concentrate on pipe making machines for more than 20 years. We have constructed many steady trading partners in Asia,Africa, middle east, Europe, and South America throughout the years. Our innovative designed production line and each single unit of the production line are not only economical but also practical.
