Ljz2-450X3700 Double-Head Saw CNC Cutting Machine for Aluminum Material for Cutting of Aluminum Alloy Curtain Wall Materials with Micro Spray Cooling Device
Shandong Zunbo CNC Equipment Co., Ltd.- After-sales Service：Lifetime Maintenance
- Warranty：1 Year
- Condition：New
- Certification：ISO, CE
- Automatic Grade：Automatic
- CNC or Not：CNC
Base Info
- Model NO.：LJZ2-450x3700
- Voltage：380V
- Numerical Control：CNC,Mnc
- Performance Classification：MID-Range CNC Machine Tools
- Application：Window
- Specification：4500*1000*1450 mm
- Trademark：Zunbo
- Origin：China
Description
Basic Info.
Model NO. LJZ2-450x3700 Voltage 380V Numerical Control CNC/Mnc Performance Classification MID-Range CNC Machine Tools Application Window Specification 4500*1000*1450 mm Trademark Zunbo Origin ChinaProduct Description
Product Description:
Model: LJZ2-450x3700Carbide saw blades have high machining accuracy and high durability.
High-precision spindle, stable rotation of the saw blade.
Hydraulic damping mechanism realizes uniform feed speed regulation and stable movement.
The feed system adopts linear guide rail movement with high precision and good stability.
The two-head saw can automatically switch.
Technical Parameter:
Power source: 380V 50HZ
Saw head motor: 3.55kW
Blade rotational speed: 2800r/min
Saw blade specification: D--450mm, d-30mm
Cutting angle: 120x300x90° and 120x300x45°
Dimensions: 4500× 1000× 1450 mm
