Woodworking Ptp Machining Center

JINAN DLM CNC ROUTER CO., LTD.
  • Certification：CE, ISO
  • Customized：Customized
  • Automatic Grade：Automatic
  • Type：Produced by Five Axis Machining Center
  • Spindle：9kw,12kw, Italy
  • Drilling Head：9V

Base Info

  • Model NO.：DA-1330B
  • Controller：Taiwan Syntec , Osai
  • Motor：Servo Motor
  • Pump：5.5kw, 7.5kw
  • Max. Cutting Speed：70m,Min
  • Racks：German Helical Rack
  • Dust Collector：3kw with Double Bags
  • Transport Package：Plywood Box
  • Specification：working area: 1300*3100*300(mm)
  • Trademark：DLM
  • Origin：China
  • HS Code：84609090
  • Production Capacity：500 Sets, Year

Description

DA-1330BTable area1300*3000mmWorking area1300*3100*300(mm)Travelling speed70 m/minCutting speed20 m/min(MAX)Spindle parametersHSD air cooling 9.0KW 24000rpmController OSSYNTECDriving systemYASKWAWorking voltageAC380V/3PH/50HZElectrical accessoriesTaiwan Delta VFD/French Schneider Low voltage electrical components/high quality cableDriving systemGerman HERION pinion/Taiwan PMI rail/Taiwan PMI ball screwTable structureGermany Schmalz Adsorption+suction cupBlanking transferBelt driveDriling units9 Vertical,6 Horizontal,and 1 Saw,Italy importsWeight4.2TVacuum system7.5KW Vacuum pumpAccessories15.5KW vacuum pump1 set2Tool box(including tools)1 set3ISO-30 Tool shank4 pcs4ER32 Collet 1/24 pcs5Standard suction cup large/smallRespectively 66Cutting tool16Woodworking Ptp Machining Center
Woodworking Ptp Machining Center
