Bohai Concealed Roof Panels Forming Machine
Yingkou Bohai Machinery Equipment Manufacture Co., Ltd.- Tile Type：Colored Steel
- Certification：CE, ISO
- Condition：New
- Customized：Customized
- Usage：Roof
- Transmission Method：Machinery
Base Info
- Model NO.：BH-RF
- Place of Origin：China
- Brand：Bohai
- Application：Construction
- Transport Package：Packed in Container
- Specification：BH-RF
- Trademark：BOHAI
- Origin：Liaoning Province of China
- Production Capacity：30 Sets Per Year
Description
Technical parameterDimension(mm): 1000× (0.4-0.8)× L Working speed: 8-12M/min Roll material: #45 forges steel plated with hard chromium Shaft material: #45 forges steel Main power: 5.5kw Hydraulic station motor power: 3kw Hydraulic pressure: 10~12 Map Control system: PLC Characteristic 1. The seat of main machine is whole welding by I-steel; the machine is welding on the seat and use vibratory stress relief to realize the stability of whole frame.
2. The main shaft is made of 45# after tempering and heat treatment, comprehensive performance is very good.
3. The unit use hydraulic forming and punching technology, choose top grade hydraulic system, working steadily, safe and effective, cutting material is Cr12, after quenching and heat treatment, the hardness is HRC62, cutting surface is smooth.
4. The controller of the unit chooses electric controller system and installed on the seat, there is no need to connect at operating time, easy and convenient. It is suitable for factory production or transport to building site. Passively de-coiling Guiding & Feeding material Roll Forming Cutting-to-length Output panel
2. The main shaft is made of 45# after tempering and heat treatment, comprehensive performance is very good.
3. The unit use hydraulic forming and punching technology, choose top grade hydraulic system, working steadily, safe and effective, cutting material is Cr12, after quenching and heat treatment, the hardness is HRC62, cutting surface is smooth.
4. The controller of the unit chooses electric controller system and installed on the seat, there is no need to connect at operating time, easy and convenient. It is suitable for factory production or transport to building site.
