Botou Hot Sale High Quality Metal Step Tile Forming Machine
HEBEI XINNUO ROLL FORMING MACHINE CO., LTD.- Product Type：Tile Making Machinery
- Automatic Grade：Automatic
- Power Source：Hydraumatic
- Screw Design：Double-Screw
- Certification：CE, ISO
- Condition：New
Base Info
- Model NO.：KXD
- Customized：Customized
- Material：PPGI, PPGL, Pre-Painted Steel Sheet
- Controller：Siemens PLC
- Yield Stress：235-345 MPa
- Thickness：0.3-1mm
- Max.Forming Speed：8-12m,Min
- Warranty：12 Month
- After-Sales Service Provided：Engineers Available to Service Machinery Overseas
- Weight：5.2t
- Voltage：380V 50Hz
- Transport Package：Sea Worthy Fixed by Wire Rope, Wooden Blocks
- Specification：8.5*1.6*1.5m
- Trademark：KXD
- Origin：China Mainland
- HS Code：84552210
- Production Capacity：8000sets ,Year
Description
main parameter of roll forming machine1 Suitable to process Color steel plate 2 Width of the plate 1200mm 3 Rollers 14 rows 4 Dimensions 8.5*1.6*1.5m 5 Power 4+3kw 6 Thickness of the plate 0.3-0.8mm 7 Productivity 8-12m/min 8 Diameter of the roller Φ80mm 9 Weight About 5.2 T 10 Voltage 380V 50Hz 3phases 11 Rolling material Carbon Steel 45# 12 Material of the cutting plate Cr12 13 Processing precision Within 1.00mm 14 Control system PLC control
ADVANTAGE
Process Sketch:
Uncoiling →Infeed guiding →Roll forming →Pressing→Measure Length&Shearing →Sheet to Support Table
Packaging & Shipping
1.One 40ft container for loading one set machine with manual decoiler;
2.The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3.Spare parts and some small parts packed in plastic tooling box;
4.All Components Fixed by steel wire with Container.
ABOUT US
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
FAQ
1:How to play order:
Inquiry---confirm the profile drawings and price----confirm the PI---arrange the deposit or L/C---then OK
2:How to visit our company:
Fly to Beijing airport:By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can
pick up you.
Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours),then we can pick up you.
3:When we exported the machines:
We have beening making and exporting the machines since from the year of 1998.
4.What's the after- sale service:
we sent technician to your country to fix the machine.The buyer should bear all the cost including:
visa, round trip ticket and suitable accommodation, also buyer should pay the salary 80USD/day.
5.How about the warranty: 12 months limits warranty
CONTACTION
Contact Person: Sunny Liu
Mob :0086 15933284089
ADVANTAGE
| Our machine | Influence of the machine | |
| Main forming machine body | High strength H350 or H400 steel. machine through milling machine after welding | Sturdy and durable, ensure the plate standard |
| Material of the roller | High grade No.45 forged steel | Ensure the forming effect of the panel and the use age will be longer,the surface of the panel |
| Material of the cutting | GCr12 steel with quenched treatment | Cutting is out of shape not easily and use age will be longer,the panel size precision |
| Material of the active shaft | High grade solid No.45 carbon steel, Shaft diameter is 72mm. | Improve the integrated mechanic feature of the shaft and keep product standard |
| Control system | PLC control system,some elements are imported from Japan and Germany | Machine become more accurate and more stable |
