High Speed Omega Purlin Solar Roll Forming Machine of Galvanized Steel for Peb Size Adjustable
Zhangjiagang City Saibo Science & Technology Co., Ltd.- Tile Type:Glazed Steel
- Certification:CE, ISO
- Condition:New
- Customized:Customized
- Usage:Roof, Wall, Floor
- Transmission Method:Electric
Base Info
- Model NO.:Omega
- Thickness:0.9-1.5mm
- Machine Structure:Wire-Electrode Cutting
- Roller Stations:About 14 Stations + One Station for Rectify
- Productivity:About 40-50m,Min
- Drive System:by Chain
- Diameter of Shaft:70mm
- Transport Package:Sea Packing
- Trademark:SAIBO
- Origin:Jiangsu, China
- HS Code:84552210
- Production Capacity:300set,Year
Description
2. Machine detailed parameters:
l X w X h
3. Specification of Components
Internal diameter of coil: variable, from380 mm to 520 mm
Maximum coil weight: 5000 Kg;
Main motor power: 7.5KW
Hydraulic power: 4kw
Speed controlled by frequency converter
Guide sheet to forming section
Change size by PLC and need change few rollers
By chain
Cutting after forming: Cut the sheet after roll forming to required length
Material of blade:Cr12, 58-62 HRC hardness
Cutting power by hydraulic,11KW
Servo power: 4KW
Length measuring: Automatic encoder length measuring
Tolerance of length: +/- 1.5mm for each piece end product
Hydraulic power: 11kw
Working pressure: maximal 25Mpa
Solenoid valve: 1 group
Hydraulic oil: 46# hydraulic oilQuantity :1
Operating system language: English and Chinese
Voltage, Frequency, Phase: 415 V, 50 Hz, 3Phase
Computer used to control length & quantity.
Machine will automatically cut to length and stop when required quantity is achievedLength inaccuracy can be amended easily.
Control panel: Button-type switch and touch screenUnit of length: millimeter
Air compressor: provide by buyer
Speed suitable for 40-50m/min
Length in 6m
warranty: 1 year warranty from date of shipment
guarantee:
1: guaranteed against malfunctions due to manufacturing defects for 1 year after date of shipment. repairs will be made free of charge.
2: repairs will not be performed free of change even during the guarantee period in the follow circumstances
- damage occurs due to a natural disaster
- malfunction occurs due to user error
- malfunction occurs due to modifications
- malfunction occurs due to further movement or shipment after installation
3: air ticket, transportation cost, hotel, meals and 80$ per day shall be for purchaser's account if manufacturer's engineer has to be send to purchaser's factory to maintain the machine during the guarantee period.
5. Application
