Qt4-15s Full Automatic Hydraulic Brick Machine Production with High Density and Strength
Linyi Chuangyun Import & Export Co., Ltd.- Certification：CE, ISO
- Customized：Customized
- Automatic Grade：Automatic
- Type：Hydraulic Shock
- Material Feeding：Automatic
- Mixer：Jq500
Base Info
- Model NO.：QT4-15s
- Products Available：Hollow Blocks, Paving Stones, Kerbstones, Hourdis
- Shaping Cycle：20-25 Seconds
- Machine Weight：3t
- Working Method：Hydraulic + Vibration
- Working Area：1000-2000m2
- Machine Capacity：5000PCS Hollow Blocks , Day
- Machine Power：27kw
- Mixer Model：Js500
- Motor：Siemens , ABB , Chinese Top Brand
- Spare Parts：Available
- Molding Cycle：15s
- Pallet Size：960*550
- Worker Number：5-6
- Transport Package：Nude Package in 20FT Container
- Specification：235 steel for machine frame
- Origin：China
- HS Code：8474802000
- Production Capacity：10 Sets , Month
Description
Dimension of host machine 4300*1850 *2600mm Pallet size 1010*550*30mm Total power 27.5kw Weight of the host machine 5.5T Vibration force 80KN Molding cycle 15s Intensity of pressure 9-10Mpa Mixer JS500 Raw Materials Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, ganaue, gravel, perlite and other industrial wastes. Applied Products Concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass block, slope blocks, interlocking blocks, etc. Applied fields Widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc.
