Customized Thickness Metal Steel Curve Roof Span Roll Forming Machine

Cangzhou Nexus Machinery Co., Ltd.
  • Tile Type：Colored Steel
  • Certification：CE, ISO
  • Condition：New
  • Customized：Customized
  • Usage：Roof, Wall
  • Transmission Method：Electric

Base Info

  • Model NO.：NM202
  • Raw Material：PPGI Sheet
  • Thickness Range：0.3-0.8mm
  • Warrenty：12 Months
  • Transport Package：Plastic Film & Steel Wire Fixed
  • Specification：2.6*1.6*1.2m(L*W*H)
  • Trademark：NEXUS MACHINERY
  • Origin：China
  • HS Code：8455221000
  • Production Capacity：30 Sets , Months

Description

Material of frame(high grade) 300mm H shape steel weldingThickness of middle plate20mmStep of curving roller7 stepsDiameter of shaft (solid shaft)70mmMaterial of shaft (solid shaft)(high grade) 45# Steel,quenching and tempering treatmentMaterial of roller45# SteelTreatment of rollerhard chromize coatedDrive type of roll forming machinedrive by hydraulic motorBearing6210 (high grade)Power of main motor4KWVoltage380V/50Hz/3phaseMotor power of hydraulic station3kwOil pump of hydraulic stationgear oil pump (high grade)Accuracy of curving+/- 2mmElectrically controlled systementire machine controlled by PLCControlling desktopTouch screen (high grade)


More Product for your choose:

Customized Thickness Metal Steel Curve Roof Span Roll Forming Machine

FAQ:

  1. Do you have after sales support?
    Yes, we are happy to give advice and also have skilled technicians available to maintain the machine if needed.
  2. What can you do if the machine broken?
    Our machine's warranty period is 12months. if the broken parts can't repair, we can send the new parts replace the broken parts, but you need pay the express cost by yourself. if after warranty period, we can through negotiation for solving the problems, and we supply the technical support for the whole life of the equipment.
  3. Can you be responsible for transport?
    Yes, please tell us the destination port or address. we have rich experience in transport.
