Lxd-200A Endface Multiple Profiles CNC Milling Machine for Doors and Windows Making with Customized Tools CNC Cutter

Shandong Zunbo CNC Equipment Co., Ltd.
  • After-sales Service:Lifetime Maintenance
  • Warranty:1 Year, 1 Year
  • Condition:New, New
  • Certification:ISO, GS, CE, RoHS, ISO 9001
  • Automatic Grade:Automatic
  • CNC or Not:CNC

Base Info

  • Model NO.:Lxd-200A
  • Voltage:380V
  • Process Usage:Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
  • Movement Method:Linear Control
  • Numerical Control:CNC,Mnc
  • Performance Classification:MID-Range CNC Machine Tools
  • After-Sales Service:Lifetime Maintenance Service
  • Application:Window
  • Specification:880*830*1390 mm
  • Trademark:Zunbo
  • Origin:China

Description

Basic Info.

Model NO. Lxd-200A Voltage 380V Process Usage Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools Movement Method Linear Control Numerical Control CNC/Mnc Performance Classification MID-Range CNC Machine Tools After-Sales Service Lifetime Maintenance Service Application Window Specification 880*830*1390 mm Trademark Zunbo Origin China

Product Description

Product Description:

Model: LXD-200
Different tools can process different structures such as stepped surfaces, rectangular grooves, and tenons.
The workbench can be adjusted up and down for convenient control.
Multiple profiles can be processed at the same time, and the tool can be customized according to the profile.
The tool feed adopts linear bearing movement, and the working performance is stable.

Technical Parameter:

Power Supply: 380 V  50 Hz
Input Power: 2.7 kW
Air Pressure: 0.5-0.8 Mpa
Air Consumption: 100 L/min
Motor Rotational Speed: 2800 r/min
Main Shaft Diameter: Φ32 mm
Milling Cutter Diameter: Φ115-200 mm
Outside Dimension: 880*830*1390 mm
