Roll Forming Machine for Decking Yx70-311-622

XIAMEN FUMING ROLL FORMING MACHINERY CO., LTD.
  • Tile Type:Gi, PPGI, Colored Steel
  • Certification:CE, SGS
  • Condition:New
  • Customized:Customized
  • Usage:Roof, Wall
  • Transmission Method:Gear,Sprocket, Gear Box or Toroidal Worm Box

Base Info

  • Color:Customized
  • Warranty:12 Months
  • Thickness:0.8mm-1.2mm
  • Feeding Width:Approx.865mm
  • Transport Package:Container
  • Specification:40GP
  • Trademark:FUMING
  • Origin:Xiamen
  • HS Code:8455229090
  • Production Capacity:15 Sets,Month

Description

YX70-311-622 ROLL FORMING MACHINEDrawing
  Material SpecificationThickness0.8mm to 1.2mmEffective width622mmFeeding widthApprox.865mmMaterialGIYield strength550MPa Machine Components5Ton*1250mm Hydraulic DecoilerCoil inner hole expandingHydraulic system, 3KW pump motorSpeed regulatingFrequency inverter, 3KW motorExpanding typeTaper wedge expanding systemLoad capacityMax.5TonsCoil Inner-diameter510±30mmCoil widthMax.1250mmStop/start rotationAutomatic stopping device with limited switch to assistOptionPlease refer to decoiler Roll Forming MachineDriving systemGear/sprocketOption for driving systemGear box or toroidal worm boxForming station18 stationsRoller material45# steel, CNC lathes, hard chrome coatedOption for roller materialCr12, Cr12MovShafts DiameterØ95mmMain motor11KW*2Line speed of rollformerApprox. 18m/min or customized Hydraulic Cutting DeviceCutting typeSlug BreakerCutting tool materialCr12, heat treatmentHydraulci pump motor5.5KW PLC Control SystemFunctionControl the quantity & cutting length automaticallyPLCSiemensTouch screenSiemensInverterDeltaEncoderOmronCut-to-length tolerance≤±2 mm or customizedControl Voltage24V Product RackUn-powered, three unitsOptionRun out table Payment TermsFOB contract: 30% payment by T/T is required as deposit within ten (10) business days since the contract signing date. 70% balance payment is required by T/T prior to shipment.CFR or CIF contract: 30% payment by T/T is required as deposit within ten (10) business days since the contract signing date. 70% balance payment is required by T/T prior to shipment or by irrevocable and non-transferable L/C at sight, to be established at least one month before shipment  WarrnantyIn correct operation & maintaining, the machine is guaranteed for one year since leaving our factory . If installation is needed, Fuming(the seller) will dispatch a technician to the buyer's factory abroad to assist commissioning the machine with charge free. The buyer should assist Fuming to get the Chinese technician's visa and should pay for the roundtrip air ticket, local accommodation and food.
