• Model NO.：6-25m
• Riding Wheel Width：100mm
• Angle of Wheel Center and Steel Mould：75°-110
• Max D of Molding Drainage Pipe：Plain Top,Tongue and Groove,Pipe-Jacking 2600,1800
• Max D of Molding Drainage：Bell and Spigot 1800mm
• Motor Power：37-90kw,55-132kw
• Speed of Main Driving Axle：100-500(Continuous) R,Min

Basic Info.

Model NO. 6-25m Riding Wheel Width 100mm Angle of Wheel Center and Steel Mould 75°-110 Max D of Molding Drainage Pipe Plain Top/Tongue and Groove/Pipe-Jacking 2600/1800 Max D of Molding Drainage Bell and Spigot 1800mm Motor Power 37-90kw/55-132kw Speed of Main Driving Axle 100-500(Continuous) R/Min

Product Description

Overview of FOCUS spun concrete pole plant:

Pre-stressed spun concrete pole plant is a kind of mould equipment, which is used for making a variety of different diameter and length of reinforced concrete poles and other cement products.

Pre-stressed spun concrete pole plant is operated by remote-controlled continuously variable motor. It runs smoothly and has a variable-speed range. So the production of concrete pipes and piles are good at quality.

The base of the machine is welded in box-type structure, sturdiness and durability. The bearings are sealed and reliable, long life. Random electric control equipment is complete and easy to use.



Working Principle of FOCUS spun concrete pole plant:

1. Adding the slurry into the mould, it is driven quickly and rotated in the same speed of the machine. Each component is separated and released under the centrifugal force. Usually the higher the slurry rotate speed, the better the slurry separating effect.

2. Centrifugal sedimentation is the use of different density of each component in the slurry, which is rotated under the centrifugal force. To realize the liquid - solid (or liquid - liquid) separation.

3. The speed of separation is slow when the viscosity of slurry is high.

4. It is good for centrifugal sedimentation when the slurry density is different in each component.



Features of FOCUS spun concrete pole plant:

1. Saving a great deal of steel, about 30~70% (employing cold drawn steel wire can save 30%~60%; employing high stress steel wire can save 40%~69%).

2. Crack resistance can increase about 3~5 times.

3. Rigidity increases 1~3 times.

4. Reducing the cost (using cold drawn steel wire can reduce 25%~40%; using high stress steel wire can reduce 12%~21%).

5. Good durability, can delay the existence and expansion of cracks.

6, Protect the environment on which human beings depend on for existence, and reduce the deforestation.

top end inner diameter (mm)	Tread (mm)	Running wheel diameter (mm)	Length (m)
150	2000	600	7-12
170	2000	600	7-12
190	2000	650	7-15
230	2000	650	6-9
300 equal diameter	2000	600	6-9
350 equal diameter	2000	650	6-12
310	2000	650-780	6-15
