• Model NO.：CNM-ZG130
• Molding Ducts Speed：Fast
• Diameter for Ducts：35mm-135mm
• Steel Strip Thickness：0.25mm, 0.28mm, 0.3mm
• Steel Strip Width：0.36mm
• Transport Package：Ply Wooden Case or Carton, or Container
• Specification：SGS, ISO9001-2008, BV
• Trademark：CNM
• Origin：Hennan Province
• HS Code：845521200
• Production Capacity：200 Sets Per Month

Basic Info.

Model NO. CNM-ZG130 Molding Ducts Speed Fast Diameter for Ducts 35mm-135mm Steel Strip Thickness 0.25mm, 0.28mm, 0.3mm Steel Strip Width 0.36mm Transport Package Ply Wooden Case or Carton, or Container Specification SGS, ISO9001-2008, BV Trademark CNM Origin Hennan Province HS Code 845521200 Production Capacity 200 Sets Per Month

Product Description

Made in China Post Tensioning Duct Making Machine Supplier

1. Model: CNM-ZG130.

2. Suitable Materials Size(steel strip): steel strip width: 36mm, thickness: 0.23-0.40mm. Such as galvanized or non-galvanized 0.23x36mm, 0.25x36mm, 0.28x36mm, 0.30x36mm, 0.32x36mm, 0.35x36mm, 0.38x36mm, 0.40x36mm.

3. Motor Voltage: Three Phase, 380V, 50HZ or Single Phase, 220V, 50HZ.

4. Producing ducts diameter:  from 35mm to 135mm.

5. Main body power: 4 KW or 7.5KW(Bigger), cutting machine power: 0.75kw.

6. Usage: Making ducts for prestressing work.

7. Applications:  It has been widely adopted by modern construction, especially used in pre-tension or post-tension for concrete constructions as building materials, such as bridge construction, railway and highway construction,  underground structures,buildings and channel construction, ect.




8. CNM-ZG130 Round Sheathing Ducts Making Machine Technical Data:

Diameter Of Ducts	35-135mm(Or Larger, Customized)
Material:	Galvanized or Non-galvanized Steel Strip
Material Thickness:	0.2mm to 0.4mm
Material Width:	36mm
Pitch Of Spiral	23mm
Seam Model	Double Lock Seam
Producing Metal Duct Speed	1. Average Speed: 13m/min,  2. Speed can be adjustable according to different diameter of ducts.
Voltage	Three Phase, 380V, 50HZ
Main Power	4kW
Cutting Machine Motor	2.2KW
Lubricant Pump Motor	40W
Weight	450KG
Dimension:	1.5mx1.3mx1.4m



9. CNM-ZGB Flat Sheathing Ducts Making Machine

ZGB flat metal ducts machine is a equipment to extrude round metal ducts make them become flat metal ducts.




10. CNM-ZGB Flat Sheathing Ducts Making Machine Technical Data:


Working Speed	9m/min
Output Duct Width	40-120mm
Suitable Ducts Outer Diameter	30-80mm
Main Motor	1.5KW
Weight	50kg
Flat Ducts Height	15-45mm(Adjustable)

11. Our Advantages:


We are PT Manufacturer from China, our full products range for post tensioning and pre-strssing construction:

1). Materials: pc strand, YJM anchor system(monostrand anchor, multistrands anchor), ducts(metal ducts, HDPE plastic ducts).

2). Equipment: Hydraulic Jack(QYC mono jack, YDC multi-strand tensioning jack), electric oil pump, YH30 embossing machie(onion jack), GYJ500 extrusion machine, ZG130 ducts making machine, grouting pump and mixer for post tensioning).

3). Bridge Equipment: Bridge Crane, Bridge Girder Launching Machine, Bridge Girder Transporting Vehicle, etc.



12. FAQ:

1). Q: What information should provide before placing order?
We are appreciated you provide us detail information about your requirement:
1. What diameter of sheathing ducts do you use?
2. What Voltage you use in your worksite?
3. What is your required Destination Port?

2) Q: How is the delivery lead time:
A: Goods in stock: within 3 days, Goods out of stock(7 days), Goods need to be customized(10-15 days).

3) What is your Minimum Order?
A: MOQ: 100 pieces.

4) Q: Payment Terms?
A TT, LC, Western Union, Paypal, etc.

5) Q: How to transport the goods:
A: by shipping, airflight, express.
