Hydraulic Bending Testing Machine (Vertical Double Working Station)

TIME GROUP INC.
  • Certification:CE, ISO
  • Customized:Non-Customized
  • Automatic Grade:Automatic
  • Type:Hydraulic Shock
  • Transport Package:Wooden Case
  • Specification:1426mm x 500mm x 1850mm

Base Info

  • Model NO.:GBW-40A
  • Trademark:TIME
  • Origin:China
  • HS Code:90241010
  • Production Capacity:1000

Description

Basic Info.

Model NO. GBW-40A Trademark TIME Origin China HS Code 90241010 Production Capacity 1000

Product Description

I Equipment Model and Name
 GBW-40A Vertical Double Working Station Hydraulic Bending Testing Machine
II Carried Standard
  GB/T 232-2010 Metal Material Bending Test Method
  GB1499.2-2007 The First Part of Steel Bar for the Reinforcement of Concrete: Hot Rolled Plain Round Steel Bars
  GB1499.2-2007 The Second Part of Steel Bar for the Reinforcement of Concrete: Hot Rolled Ribbed Steel Bars and other related standard request.
III Equipment Brief Introduction
  GBW-40A type a vertical double working station hydraulic bending testing machine adopts the combination technology of hydraulic loading and single chip microcomputer system , it is mainly used for the bending test for metal or nonmetal material or product manufacturability. It is composed of the test host, oil source (hydraulic power source), measurement and control system, test instruments of four parts.

40A type bending testing machine meet the GB/T 232-99 metal material bending test requirements. Bending distance through the level of oil cylinder stroke control, which is very convenient.
  Test force does not step all the test, the resolution is better than 1.5 N, test forces of relative error within
±1%, test range 1% - 100%.
  The tester can be used in metallurgical construction quality inspection department, production enterprise deformed steel bar bending, can also be used for construction materials, steel welding point bending performance testing, which is the commonly used equipment for metallurgical enterprises, research institutes, quality inspection, construction, railway, transportation, colleges and universities and the non-ferrous metal industry material bending performance test and study.

IV Specification and Parameter
1. Round specimen max. Bending diameter: Φ40mm
2. Flat specimen max. Bending thickness:   20mm
3. Bending angle range::       0~180°(Using displacement instead)
4. Displacement measurement resolution:          0.008
5. System max. Working pressure:     31.5MPa
6. Roller specification:                   Φ40*140
7. Bending diameter range:      D6160(For the user to choose configuration )
8. Longitudinal bending max. Test force:         300KN
9. Vertical piston working distance:           270mm
10. Double working station clamping rating pressure: 160KN*2
11. Double working station single piston distance:   200mm
12. Piston travelling speed:            V1=80mm/min
13. Piston return speed:              V2=160mm/min
14. Motor power :              N=1.5KW
15. Working voltage :              380V/220V
16. Dimension                    1426×500×1850mm
17. Weight                     1020Kg
