Pipe Machine Air Making Manufacturing Rectangular Duct Production Line 5/6
Maanshan SPR Machine Co., Ltd.- After-sales Service：Online Support, Free Spare Parts, Field Installati
- Automatic Grade：Full-Automatic
- Warranty：1 Year
- Power：30kw
- Key Selling Points：Easy to Operate
- Dimension(L*W*H)：12000*5500*1500,12000*6300*1500mm
Base Info
- Sheet Thickness (mm)：0.5-1.2mm
- Application：Carbon Steel Duct Making
- Function：Duct Work
- Coiler Max Weight：7t
- Pipe Shape：Rectangle Pipe
- Certification：CE
- Transport Package：Seaworthy Package
- Specification：3kg
- Trademark：sipairui
- Origin：China
- HS Code：8462490000
- Production Capacity：100 Pieces ,Year
Description
Weight (T)
The I-type stainless steel duct production V line is mainly used for rectangular duct production, from coil material to duct finished product, assembly line operation, fully automated production; advanced technology, high degree of automation, and high production efficiency. It is also suitable for cut-to-length blanking of sheets, processing of cabinets and household appliances, automobiles, elevators and other light industry sectors. This production line has the characteristics of simple operation, stable performance, precise blanking control size, and small footprint.
Using this machine to make air ducts has reliable quality and meets customer requirements. It also has the following characteristics:
1. It is used for the blanking of common plate flanges, angle steel flanges, and hook flange (CS bone) plates, and can also be specially used for plate blanking;
2. Adopt advanced numerical control, hydraulic control, pneumatic control system, which makes the operation of the whole system stable and improves the accuracy of processing;.
Basic Configuration:
1. Four electric coil cradles,4 material trays (5-7t each roll);
2. One rack;
3. One host (line 2 host);
4. One mechanical arm clutching, locating and transferring platform;
5. One movable type lock forming machine;
6. One duplex TDF flange forming machine;
7. One duplex angle steel flange forming machine;
8. One hydraulic folding machine;
9. One set of computer controlling system.
1) The altitude does not exceed 1000 meters;
2) Ambient temperature: -5ºC~+40ºC;
3) Relative air humidity: 20%~80%;
4) Atmospheric conditions: there must be no medium (gas, dust, etc.) that is corroded by thunderstorms and causes explosions, metal corrosion, or damage to insulation;
5) Main power supply: AC380V±10% Frequency: 50Hz;
6) Working height: 920mm;
7) Weight of the whole machine: ≈16t
8) Total power of the whole machine: ≈35Kw
9) Overall dimensions of the whole machine: L×W×H==5400*2400*1800
Function:
It's mainly for TDF / angle steel / C-shaped flange forming with daily processing capability of
1000-2500 square meters. Only with inputting dimensions in duct, production line can
automatically complete uncoiling, leveling,beading, punching, shearing, locking, forming TDF
angle steel / C-shaped flange and folding.
product details
Product Real Picture
