Metal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production Line

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Certification：ISO, CE, SGS
  • Color：Green

Base Info

  • Model NO.：door frame roll forming machine
  • Control System：PLC
  • Rolller：High Grade 45# Steel
  • Froming Steps：13
  • Hydraulic Pump Station：4kw
  • Motor Power：5.5kw
  • Chain：1inch
  • Cutter：Cr12
  • Middle Plate：14mm
  • Shaft：75mm
  • Transport Package：Nude, Covered with Plastic Film
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Botou, Hebei, China
  • HS Code：84552210
  • Production Capacity：30 Sets,Month

Description

Main parameter for1Suitable to processGalvanized/Aluminum/Color steel sheet2Width of plate1250mm3Thickness of plate0.3-0.8mm4RollersHigh grade 45# steel, with hard chrome plating5Forming steps166Sprocket chain1.5 inch7Pump station power4kw8Shaft75mm, high grade 45# steel, heat treatment9Hydraulic oil pumpCB-E31010WeightAbout 5.0 tons11Productivity8-12m/min12Cutting headCr12 mould steel with quenched treatment13Control systemTAIDA brand PLC control14Voltage380V 3Phase 60Hz15Motor power4kw16DimensionAbout 6.8m*1.5m*1.5m17Hydraulic pressure10-12mpa18Index error of length±1mm19The temperature range of working line-35-50°Metal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production LineMetal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production LineMetal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production LineMetal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production LineMetal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production Line



Equipment Use:Equipment of plate type is suitable for large factory,temporary housing,Outdoor steel structure roof panel,beautiful,Suitable for outdoor building,The plate for the lap type structure.

After-sales service and installation:Our factory with perfect after-sales service,And can according to user requirements design and manufacture of the special type,To the user guide at the same time, production, installation, debugging, maintenance.

Machine Features: Our sales of such type of tile press, by domestic and foreign customers consistent high praise, The equipment of exquisite workmanship, plate type standard, its biggest characteristic is suitable for site use, Good anticorrosive property, is the first choice for customers.
Above all the parameters can be changed exactly according to customer's requirements.
4. Advantage of DIXIN roll forming machineNo.DIXIN roll forming machine1High grade quality2Reasonable price3High efficiency4Low failure rate5Low energy consumption6Free after-sale service7Reliable working8Durable9Wide application10Beautiful appearance11Welcomed by all over the world customers12Professional foreign trade team13Mature technician team14Customize special type5. Want a free quotation for make budget?
Just send inquiry to me now!
6. We are your reliable partner!
We always do the best to make our machine perfect in every detail part.
Any pics or videos about machine, we can provide you.
7. Payment terms
30% T/T as the deposit when contract signed, 70% balanced before shipping.
8.Company information
Metal Aluminum Color Door Frame Making Equipment Steel Roll Forming Making Machine Production Line

If you have any question,please contact me!
