• Model NO.：Customization
• Rhythm：Flow Production Line
• Transmission Type：Flexible
• Materials：Steel
• Speed：3-18m,Min
• Type：Concrete Iron Connection Machinery
• Method：Autoclaved Aerated Concrete
• Processing：Brick Production Line
• Product：Composite Material
• Automation：Automatic
• Transport Package：Standard Export Package
• Specification：SGS
• Trademark：CMT
• Origin：Jiangsu Suzhou

Basic Info.

Model NO. Customization Rhythm Flow Production Line Transmission Type Flexible Materials Steel Speed 3-18m/Min Type Concrete Iron Connection Machinery Method Autoclaved Aerated Concrete Processing Brick Production Line Product Composite Material Automation Automatic Transport Package Standard Export Package Specification SGS Trademark CMT Origin Jiangsu Suzhou

Product Description

A) Pu Line Application:

This line is for wall and roof PU sandwich panel producing, the PU sandwich panel have function of sound insulation, heat insulation and prevent burn and use in wall panel,roof panel ,cold storage panel and so on.

B) Line Structure:

l The line is total automatic continuous PU production line unit, with composite machine to get to produce wall panel and roof panel bayonet Pu sandwich panel, at the same time the output panel thickness is adjustable, see the specific panel drawing.
l Composite machine adopts belt type with the character of light,simple and good sealing.
l The whole line is controlled automatically by PLC, the productivity effenciency improved much.

 Flow chart:
Coil --- Decoiler --- Feeding --- Forming --- Roller Delivery --- Steel Sheet Pre-heating --- Foaming --- Composite Machine --- Roller Delivery --- Post Trace Cutting --- Roller Delivery --- Manual Package

C) Components:


Manual Decoiler	2 SETS
Roll Forming System	1SETS
Front Tensile shearing equipment	2 SETS
Delivery roller	2 SETS
Pre-heating equipment(pre-heating house)	1 SET
Composite forming machine	1 SET
Post cutting equipment	1 SET
PLC Controlling system	1 SET
Foaming system	1 SET
Hydraulic system:	1 SET
Air pressure system	1 SET

For more information,pls feel free to contact us.
